单倍体酿酒酵母的丙酮酸脱羧酶基因(pdc1)的敲除与鉴定

doi:10.11924/j.issn.1000-6850.casb20190600332

中国农学通报 ›› 2020, Vol. 36 ›› Issue (24): 91-98.doi: 10.11924/j.issn.1000-6850.casb20190600332

所属专题：生物技术

单倍体酿酒酵母的丙酮酸脱羧酶基因(pdc1)的敲除与鉴定

康杰¹^,²(), 王长丽¹^,², 葛菁萍¹^,²()

¹黑龙江大学农业微生物技术教育部工程研究中心,哈尔滨 150080
²微生物黑龙江省高校重点实验室/黑龙江大学生命科学学院,哈尔滨 150500

收稿日期:2019-06-25 修回日期:2019-07-10 出版日期:2020-08-25 发布日期:2020-08-20
通讯作者: 葛菁萍
作者简介:康杰,男,1995年出生,研究生,研究方向：微生物学。通信地址：150080 黑龙江省哈尔滨市南岗区学府路74号黑龙江大学224信箱,Tel：0451-86609016,E-mail：kangjie182@126.com。
基金资助:
国家自然科学基金“从2,3-丁二醇代谢角度构建工程微生物群体及其生态学机制研究”(31570492);黑龙江省教育厅重点项目“利用肺炎克雷伯氏菌发酵生产2,3-丁二醇及机理探讨”(HDJCCX-2016Z05);黑龙江省自然科学基金重点项目“乙酸代谢与副干酪乳杆菌群体感应互作探究及对细菌素产生的影响”

Pyruvate Decarboxylase Gene (pdc1) of Haploid Saccharomyces Cerevisiae: Knockout and Identification

Kang Jie¹^,²(), Wang Changli¹^,², Ge Jingping¹^,²()

¹Agricultural Microorganisms Technology Education Engineering Research Center, Harbin 150080
²Key Laboratory of Microbiology of Heilongjiang Province, Life Science College, Heilongjiang University, Harbin 150500

Received:2019-06-25 Revised:2019-07-10 Online:2020-08-25 Published:2020-08-20
Contact: Ge Jingping

摘要/Abstract

摘要：

为了抑制单倍体酿酒酵母H14的副产物乙醇的合成,使得2,3-丁二醇产量的提升。利用基因工程手段构建载体pWCL-pdc1,获得两端含40 bp pdc1的同源重组片段-loxP-kanMX-loxP。利用Cre/loxP技术获得pdc1缺失菌株S. cerevisiae H14-01 (△pdc1)。并以野生型菌株S. cerevisiae H14为对照,进行摇瓶发酵试验。S. cerevisiae H14-01长势明显略低于原始菌株。在整个发酵期间,2,3-丁二醇的最高产量和转化率分别为0.373±0.016 g/L和0.005 g/g,分别较原始菌株提高了37.30%和4.66%,但原始菌株没有检测到乙偶姻和2,3-BD生成。另外S. cerevisiae H14-01的乙醇转化率降低了33.24%,但甘油产量提高了15.76%。说明了碳流流向乙醇被阻断之后,会增加2,3-丁二醇的产量,同时会使此部分碳流流向甘油。因此,并为进一步获得高产2,3-丁二醇的工程微生物群体奠定了基础。

关键词: 酿酒酵母, 2,3-丁二醇, Cre/loxP技术, 丙酮酸脱羧酶, 基因敲除

Abstract:

The aim is to inhibit the synthesis of ethanol, a by-product of haploid Saccharomyces cerevisiae H14, and increase the yield of 2,3-butanediol. The vector pWCL-pdc1 was constructed by genetic engineering to obtain the homologous recombinant fragment loxP-kanMX-loxP containing 40 bp pdc1 at both ends. The pdc1 deleted strain S. cerevisiae H14-01 (Δpdc1) was obtained by Cre/loxP technique. The shaking flask fermentation experiment was carried out with the wild type strain S. cerevisiae H14 as the control. The growth of S. cerevisiae H14-01 was significantly lower than that of the original strain. During the whole fermentation period, the maximum yield and conversion rate of 2,3-butanediol were 0.373 ±0.016 g/L and 0.005 g/g, respectively, which were 37.30% and 4.66% higher than that of the original strain, respectively. However, acetoin and 2,3-BD production was not detect in the original strain. In addition, the ethanol conversion of S. cerevisiae H14-01 decreased by 33.24%, but the glycerol production increased by 15.76%. It showed that after the carbon flow to ethanol was blocked, the production of 2, 3-butanediol could be increased, and part of the carbon flow will flow to glycerol. Therefore, the study lays a good foundation for further obtaining an engineering microbial population with high yield of 2,3-butanediol.

Key words: Saccharomyces cerevisiae, 2,3-butanediol, Cre/loxP technology, pyruvate decarboxylase, gene knockout

中图分类号:

Q933

康杰, 王长丽, 葛菁萍. 单倍体酿酒酵母的丙酮酸脱羧酶基因(pdc1)的敲除与鉴定[J]. 中国农学通报, 2020, 36(24): 91-98.

Kang Jie, Wang Changli, Ge Jingping. Pyruvate Decarboxylase Gene (pdc1) of Haploid Saccharomyces Cerevisiae: Knockout and Identification[J]. Chinese Agricultural Science Bulletin, 2020, 36(24): 91-98.

图/表 12

图1. 转化子的PCR验证示意图

图2. 阳性质粒单酶切验证 M1、M2：DNA Marker DL 15000和DL 2000;1、2：pMDTM18-T和pTWCL-pdc1酶切产物

图3. pdc1-loxP-kanMX转化S. cerevisiae H14 A对照组,B实验组

图4. 阳性克隆子的菌液PCR验证 M：DNA Marker DL 2000;1、2、3、4、8：阳性克隆菌液PCR扩增kanMX

图5. pdc1-B1和pdc1-C1引物对PCR扩增验证 M：DNA Marker DL 2000;2、5、6、9、10、11：PCR扩增基因组kanMX片段

图6. 基因组PCR扩增验证 M：DNA Marker DL 2000;1~4：基因组PCR扩增产物;A：引物对pdc1-A1和pdc1-B1;B：引物对pdc1-A1和pdc1-D1;C：引物对pdc1-C1和pdc1-D1

图7. 含pSH69质粒的阳性转化子的筛选△pdc1/H14

图8. 消除G418抗性菌株的筛选△pdc1/H14

图9. 琼脂糖凝胶电泳验证pdc1基因 M：DNA Marker DL2000;1~3：基因组PCR扩增产物

图10. H14/H14-△pdc1的乙醇转化率比较

图11. H14/H14-△pdc1-1的OD600、葡萄糖剩余量、乙偶姻和2,3-丁二醇浓度比较

图12. H14/H14-△pdc1-1的甘油和乙醇含量比较

参考文献 31

[1]	Garg S K, Jain A. Fermentative production of 2,3-butanediol-a review [Review][J]. Bioresource Technology, 1995,51(3):103-109. doi: 10.1016/0960-8524(94)00136-O URL
[2]	Yang T W, Rao Z M, Zhang X, et al. Effects of corn steep liquor on production of 2,3-butanediol and acetoin by Bacillus subtilis[J]. Process Biochemistry, 2013,48(11):1610-1617. doi: 10.1016/j.procbio.2013.07.027 URL
[3]	付晶, 王萌, 刘维喜, 等. 生物法制备2,3-丁二醇的最新进展[J]. 化学进展, 2012,24(11):2268-2276.
[4]	Lian J, Chao R, Zhao H. Metabolic engineering of a Saccharomyces cerevisiae strain capable of simultaneously utilizing glucose and galactose to produce enantiopure (2R, 3R)-butanediol[J]. Metabolic Engineering, 2014,23(5):92-99. doi: 10.1016/j.ymben.2014.02.003 URL
[5]	Bae S J, Kim S, Hahn J S. Efficient production of acetoin in Saccharomyces cerevisiae by disruption of 2,3-butanediol dehydrogenase and expression of NADH oxidase[J]. Scientific Reports, 2016,6:27667. doi: 10.1038/srep27667 URL pmid: 27279026
[6]	Kim S, Hahn J S. Efficient production of 2,3-butanediol in Saccharomyces cerevisiae by eliminating ethanol and glycerol production and redox rebalancing[J]. Metabolic Engineering, 2015,31:94-101. doi: 10.1016/j.ymben.2015.07.006 URL pmid: 26226562
[7]	Choo J H, Han C, Lee D W, et al. Molecular and functional characterization of two pyruvate decarboxylase genes, pdc1 and pdc5, in the thermotolerant yeast Kluyveromyces marxianus[J]. Applied Microbiology and Biotechnology, 2018,102(8):3723-3737. doi: 10.1007/s00253-018-8862-3 URL pmid: 29497799
[8]	Kata I, Semkiv M V, Ruchala J, et al. Overexpression of the genes pdc1 and adh1 activates glycerol conversion to ethanol in the thermotolerant yeast Ogataea (Hansenula) polymorpha[J]. Yeast, 2016,33(8):471-478. doi: 10.1002/yea.3175 URL pmid: 27256876
[9]	Kim D M, Choi S-H, Ko B S, et al. Reduction of pdc1 expression in S. cerevisiae with xylose isomerase on xylose medium[J]. Bioprocess and Biosystems Engineering, 2012,35(1-2):183-189. doi: 10.1007/s00449-011-0638-4 URL
[10]	Tokuhiro K, Ishida N, Nagamori E, et al. Double mutation of the pdc1 and adh1 genes improves lactate production in the yeast Saccharomyces cerevisiae expressing the bovine lactate dehydrogenase gene[J]. Applied Microbiology and Biotechnology, 2009,82(5):883-890. doi: 10.1007/s00253-008-1831-5 URL
[11]	Wah Tang P, San Chua P, Kee Chong S, et al. A review of gene knockout strategies for microbial cells[J]. Recent Patents on Biotechnology, 2016,9(3):176-197. doi: 10.2174/1872208310666160517115047 URL pmid: 27185502
[12]	叶广彬, 郭睿, 孙珊珊, 等. λRed技术构建产酸克雷伯氏菌乙酸激酶基因缺失突变株[J]. 黑龙江大学自然科学学报, 2018,35(03):334-341.
[13]	Shan Q, Zhang Y, Chen K, et al. Creation of fragrant rice by targeted knockout of the OsBADH2 gene using TALEN technology[J]. Plant Biotechnology Journal, 2015,13(6):791-800. doi: 10.1111/pbi.12312 URL pmid: 25599829
[14]	Hauschild Quintern J, Petersen B, Cost G J, et al. Gene knockout and knockin by zinc-finger nucleases: current status and perspectives[J]. Cellular and Molecular Life Sciences: CMLS, 2013,70(16):2969-2983. doi: 10.1007/s00018-012-1204-1 URL pmid: 23161061
[15]	Kawai S, Hashimoto W, Murata K. Transformation of Saccharomyces cerevisiae and other fungi[J]. Bioeng Bugs, 2010,1(6):395-403. doi: 10.4161/bbug.1.6.13257 URL pmid: 21468206
[16]	江璐. 酿酒酵母单倍体的分离及其发酵特性研究[D]. 杨凌:西北农林科技大学, 2014.
[17]	王长丽, 佟天奇, 刘文娟, 等. 酿酒酵母W5单倍体的制备及其代谢水平分析[J]. 食品科学, 2018,39(08):57-63.
[18]	Xu W, Wang J, Li Q. Induction, separation and identification of haploid strains from industrial brewer's yeast[J]. Wei Sheng Wu Xue Bao= Acta Microbiologica Sinica, 2015,55(1):22-32. URL pmid: 25958679
[19]	Enik Z R, Karolina C, Gjuvsland A B, et al. Ancient evolutionary trade-offs between yeast ploidy states[J]. Plos Genetics, 2013,9(3):e1003388. doi: 10.1371/journal.pgen.1003388 URL pmid: 23555297
[20]	Mei G Y, Bajwa P K, Dashtban M, et al. Transfer of plasmid into the pentose-fermenting yeast Pachysolen tannophilus[J]. Journal of microbiological methods, 2018,148:97-103. doi: 10.1016/j.mimet.2018.03.013 URL pmid: 29596958
[21]	Hal A, Joel M, Elke N, et al. Engineering yeast transcription machinery for improved ethanol tolerance and production[J]. Science, 2006,314(5805):1565-1568. doi: 10.1126/science.1131969 URL pmid: 17158319
[22]	Milani E A, Gardner R C, Silva F V M. Thermal resistance of Saccharomyces yeast ascospores in beers[J]. International Journal of Food Microbiology, 2015,206:75-80. doi: 10.1016/j.ijfoodmicro.2015.04.002 URL pmid: 25996521
[23]	Kim J W, Seo S O, Zhang G C, et al. Expression of Lactococcus lactis NADH oxidase increases 2,3-butanediol production in Pdc-deficient Saccharomyces cerevisiae [J]. Bioresource Technology, 2015,191:512-519. doi: 10.1016/j.biortech.2015.02.077 URL
[24]	Thanh T N, Jurgen B, Bauch M, et al. Regulation of acetoin and 2,3-butanediol utilization in Bacillus licheniformis [J]. Applied Microbiology and Biotechnology, 2010,87(6):2227-2235. doi: 10.1007/s00253-010-2681-5 URL
[25]	Hubmann G, Guillouet S, Nevoigt E. Gpd1 and Gpd2 fine-tuning for sustainable reduction of glycerol formation in Saccharomyces cerevisiae[J]. Applied and Environmental Microbiology, 2011,77(17):5857-5867. doi: 10.1128/AEM.05338-11 URL
[26]	Petrov K, Petrova P. High production of 2,3-butanediol from glycerol by Klebsiella pneumoniae G31[J]. Applied Microbiology and Biotechnology, 2009,84(4):659-665. doi: 10.1007/s00253-009-2004-x URL
[27]	Petrov K, Petrova P. Enhanced production of 2,3-butanediol from glycerol by forced pH fluctuations[J]. Applied Microbiology and Biotechnology, 2010,87(3):943-949. doi: 10.1007/s00253-010-2545-z URL
[28]	Xin F, Basu A, Weng M C, et al. Production of 2,3-Butanediol from sucrose by a Klebsiella Species[J]. BioEnergy Research, 2015,9(1):15-22.
[29]	Kim S J, Seo S O, Park Y C, et al. Production of 2,3-butanediol from xylose by engineered Saccharomyces cerevisiae[J]. Journal of Biotechnology, 2014,192:376-382. doi: 10.1016/j.jbiotec.2013.12.017 URL pmid: 24480571
[30]	Siemerink M A, Kuit W, Lopez Contreras A M, et al. D-2,3-butanediol production due to heterologous expression of an acetoin reductase in Clostridium acetobutylicum[J]. Applied and Environmental Microbiology, 2011,77(8):2582-2588. doi: 10.1128/AEM.01616-10 URL pmid: 21335380
[31]	龙定沛, 谭兵, 赵爱春, 等. Cre/lox位点特异性重组系统在高等真核生物中的研究进展[J]. 遗传, 2012,34(02):177-189.
