2种丽细蛾触角感受器超微结构特征

doi:10.11924/j.issn.1000-6850.casb2021-0505

摘要/Abstract

摘要：

茶丽细蛾和黑丽细蛾分别是山茶科和槭树科部分植物的潜叶害虫。旨在通过观察掌握2种丽细蛾触角感受器的类型、数量、分布及形态特征,探讨触角感受器特征在种内和种间的差异性。用扫描电镜观察触角感受器的类型及形态特征并测量特征值。2种丽细蛾的触角感受器共11种类型16种亚型,分别是毛形感受器（2种亚型）、刺形感受器（2种亚型）、腔锥形感受器（2种亚型）、栓锥形感受器（3种亚型）、耳形感受器（3种亚型）、锥形感受器、鳞形感受器（2种亚型）、节间感受器（2种亚型）、Böhm氏鬃毛、乳突感受器和片刺形感受器。茶丽细蛾雌性有11种（11种亚型）感受器,雄性有10种（13种亚型）。黑丽细蛾雌性和雄性均有10种感受器,13种亚型。雌性茶丽细蛾鞭节第1亚节有半融合现象。2种丽细蛾的触角感受器均有性二型现象,在种间也具有一定的差异性。节间感受器、乳突感受器和片刺形感受器在鳞翅目昆虫中首次报道。研究结果丰富了细蛾科乃至鳞翅目昆虫触角感受器的类型,可为深入研究细蛾科昆虫系统发育关系、行为特征、害虫防治等提供基本依据。

关键词: 触角感受器, 性二型, 丽细蛾, 细蛾科, 扫描电镜

Abstract:

Caloptilia theivora and Caloptilia kurokoi are the leaf-miners of some plants respectively belonging to the family of Theaceae and Aceraceae. The study aims to understand the types, quantities, distribution and morphological characteristics of the antennal sensilla of the two species of Caloptilia, and explore their intraspecific and interspecific differences of antennal sensilla characteristics. Scanning electron microscope was used for the analysis. There are 11 types and 16 subtypes of antennal sensilla of the two species of Caloptilia, including sensilla trichodea (2 subtypes), sensilla chaetica (2 subtypes), sensilla coeloclnica (2 subtypes), sensilla styloconica (3 subtypes), sensilla auriculate (3 subtypes), sensilla basiconca, sensilla squamiformia (2 subtypes), sensilla intersegment (2 subtypes), Böhm bristles, sensilla mammilliformia and sensilla lamellar spiny. The female Caloptilia theivora has 11 types of sensilla (11 subtypes) and the male one has 10 types (13 subtypes). Both female and male Caloptilia kurokoi have 10 types and 13 subtypes of antennal sensilla. Semifusion was observed in the first subsegment of the flagellum of the female Caloptilia theivora. Both the two species of Caloptilia have sexual dimorphism in antennal sensilla, and there are some interspecific differences. Sensilla intersegment, sensilla mammilliformia and sensilla lamellar spiny are first reported in Lepidopteran. The antennal sensilla types of Gracillariidae and even Lepidoptera are greatly enriched by the research, which can lay a basis for further exploring the phylogenetic development, behaviors and pest and insect control of Gracillariidae.

Key words: antennal sensilla, sexual dimorphism, Caloptilia, Gracillariidae, scanning electron microscope

中图分类号:

S476

梁景璇, 白海艳. 2种丽细蛾触角感受器超微结构特征[J]. 中国农学通报, 2022, 38(16): 110-118.

LIANG Jingxuan, BAI Haiyan. Ultra-structural Characteristics of the Antennal Sensilla of Two Species of Caloptilia (Lepidoptera: Gracillariidae)[J]. Chinese Agricultural Science Bulletin, 2022, 38(16): 110-118.

图/表 4

参考文献 33

[1]	余海忠. 昆虫触角感受器研究进展[J]. 安徽农业科学, 2007, 35(14):4238-4240.
[2]	刘一博, 刘俊峰, 马烨,等. 昆虫化学通讯之谜[J]. 应用昆虫学报, 2020, 57(5):1056-1063.
[3]	FAUCHEUXA M J, KRISTENSENB N P, YEN S H. The antennae of neopseustid moths: Morphology and phylogenetic implications, with special reference to the sensilla (Insecta, Lepidoptera, Neopseustidae)[J]. Zoologischer anzeiger-A journal of comparative zoology, 2006, 245(2):131-142.
[4]	SUN E, BOHBOT J D, ZWIEBEL L J. Peripheral olfactory signaling in insects[J]. Current opinion in insect science, 2014, 64(6):86-92.
[5]	KIM J Y, LEAL W S. Ultrastructure of pheromone-detecting sensillum placodeum of the Japanese beetle, Popillia japonica Newmann (Coleoptera: Scarabaeidae)[J]. Arthropod structure & development, 2000, 29(2):121-128.
[6]	LIU Y, HE J, ZHANG R, et al. Sensilla on antenna and maxillary palp of Neoceratitis asiatica (Diptera: Tephritidae)[J]. Micron, 2020,138.
[7]	LIU F, LI F, ZHANG S, et al. Ultrastructure of antennal sensilla of Erannis ankeraria Staudinger (Lepidoptera: Geometridae)[J]. Microscopy research and technique, 2019, 82(11):1903-1910.
[8]	DA SILVA K B, DA SILVA C B, et al. LISBOA Ribeiro Júnior K A, Morphology and distribution of antennal sensilla of Automeris liberia (Lepidoptera: Saturniidae)[J]. Micron, 2019,123.
[9]	ZHANG Y J, CHEN D Y, CHAO X T, et al. Morphological characterization and distribution of antennal sensilla of Diaphania angustalis Snellen (Lepidoptera: Crambidae)[J]. Microscopy research and technique, 2019, 82(2):1632-1641. doi: 10.1002/jemt.23329 URL
[10]	郭永福, 王怡, 孔维娜,等. 梨小食心虫触角感受器雌雄二型的超微研究[J]. 环境昆虫学报, 2018, 40(4):950-957.
[11]	向玉勇, 杨茂发, 李子忠. 小地老虎雄蛾触角感受器的扫描电镜观察[J]. 四川动物, 2009, 28(3):390-393.
[12]	郭文华, 白海艳. 两种苔蛾触角感器扫描电镜观察[J]. 电子显微学报, 2017, 36(4):384-391.
[13]	江南, 李庆, 周建华,等. 麻疯树柄细蛾触角及其感器的扫描电镜观察[J]. 昆虫知识, 2010, 47(2):355-359.
[14]	辛文, 李鑫, 孟山栋,等. 金纹细蛾触角感器的扫描电镜观察[J]. 西北农业学报, 2016, 25(7):1103-1110.
[15]	赵之亭, 李鹏燕, 陈炳旭,等. 荔枝蛀蒂虫触角的超微结构观察[J]. 广东农业科学, 2012, 39(12):85-86.
[16]	张辉, 江世宏, 陈晓琴. 荔枝蒂蛀虫雄蛾触角感受器的扫描电镜观察[J]. 福建农林大学学报:自然科学版, 2013, 42(3):230-232.
[17]	白海艳, 铁军, 侯沁文. 中国细蛾科寄主植物多样性分析[J]. 昆虫学报, 2018, 61(9):1067-1075.
[18]	CHEN S C, JIANG H Y, SHANG J, et al. Characterization of the complete mitochondrial genome of the tea leaf roller Caloptilia theivora (Insecta: Lepidoptera: Gracillariidae)[J]. Mitochondrial DNA B-Resources, 2019, 4(2):2211-2212.
[19]	SCHNEIDER D. Insect antennae[J]. Annual review of entomology, 1964, 9(1):103-122. doi: 10.1146/annurev.en.09.010164.000535 URL
[20]	马瑞燕, 杜家纬. 昆虫的触角感器[J]. 昆虫知识, 2000, 37(3):179-183.
[21]	刘志雄, 刘红霞, 张金桐,等. 柳毒蛾的触角结构与感受器扫描电镜观察[J]. 电子显微学报, 2015, 34(3):257-260.
[22]	赵立静, 班丽萍. 蚜虫触角感受器结构及功能研究进展[J]. 应用昆虫学报, 2011, 48(4):1077-1086.
[23]	孙伊阳, 覃东玉, 潘丽娜,等. 白蛾周氏啮小蜂触角感受器性二型超微结构分析[J]. 林业科学, 2020, 56(10):135-144.
[24]	ENNO M, ANGELA P, MÄRT R, et al. Antennal sensilla of the ground beetle Bembidion properans Steph. (Coleoptera, Carabidae)[J]. Micron, 2002, 33(5):429-440. doi: 10.1016/S0968-4328(02)00003-3 URL
[25]	GOMEZDIAZ C, MARTIN F, GARCIAFERNANDEZ J M, et al. The two main olfactory receptor families in Drosophila, ORs and IRs: A comparative approach[J]. Frontiers in cellular neuroscience, 2018, 12(8):253-267. doi: 10.3389/fncel.2018.00253 URL
[26]	ARUNA R, JEYARANI S, MOHANKUMAR S, et al. Documentation and validation of chemosensory structures in antennae of Spodoptera litura (Fabricius) through scanning electron microscope (SEM)[J]. Indian journal of agricultural research, 2019, 53(5):554-559.
[27]	SIEW Y Q, NGAN K C, PETER S. The physicochemical properties of spray-dried watermelon powders[J]. Chemical engineering and processing, 2007, 46(5):387-392.
[28]	狄贵秋, 马庆辉, 马维超,等. 美国白蛾触角感器超微结构[J]. 东北林业大学学报, 2020, 48(3):95-99.
[29]	ANDERSON P, HANSSON B S, LOFQVIST J. Plant-odour-spcific receptor neurones on the antennae of female and male Spodoptera littoralis[J]. Physiological entomology, 1995, 20(3):189-198. doi: 10.1111/j.1365-3032.1995.tb00001.x URL
[30]	LIU H X, LIU Z X, JING X Y, et al. Scanning electron microscopy studies of antennal sensilla of Isoceras sibirica Alpheraky (Lepidoptera, Cossidae)[J]. Annales de la Société entomologique de France (N.S.), 2014, 50(3):350-357.
[31]	OLSON D M, ANDOW D A. Antennal sensilla of female Trichogramma nubilale (Ertle and Davis) ( Hymenoptera: Trichogrammatidae) and comparisons with other parasitic Hymenoptera[J]. International journal of insect morphology and embryology, 1993, 22(5):507-520. doi: 10.1016/0020-7322(93)90037-2 URL
[32]	MULLER M L, HONEGGER H W, NICKEL E, et al. The ultrastructure of campaniform sensilla on the eye of the cricket, Gryllus campestris[J]. Cell and tissue research, 1978, 195(2):349-357.
[33]	邓顺, 舒金平, 董双林,等. 笋秀夜蛾触角感器的扫描电镜观察[J]. 林业科学, 2010, 46(12):101-105.

触角形态	茶丽细蛾		黑丽细蛾
触角形态	雌	雄	雌	雄
柄节	201.67±5.93a	232.17±14.90ab	264.33±20.99b	191.67±5.74bc
梗	83.53±2.77a	84.75±1.44a	85.93±2.46a	83.00±1.23a
鞭节	6827.00±175.89a	6236.13±135.14b	6873.00±74.88b	7523.00±74.88c
全长	7157.2±220.94a	6553.05±127.08b	7223.27±70.28b	7797.67±60.58c

触角形态	茶丽细蛾		黑丽细蛾
触角形态	雌	雄	雌	雄
柄节	201.67±5.93a	232.17±14.90ab	264.33±20.99b	191.67±5.74bc
梗	83.53±2.77a	84.75±1.44a	85.93±2.46a	83.00±1.23a
鞭节	6827.00±175.89a	6236.13±135.14b	6873.00±74.88b	7523.00±74.88c
全长	7157.2±220.94a	6553.05±127.08b	7223.27±70.28b	7797.67±60.58c

感器类型		性别	茶丽细蛾				黑丽细蛾
感器类型		性别	数量	长度/μm	基部直径/μm	臼状窝直径/μm	数量	长度/μm	基部直径/μm	臼状窝直径/μm
Str	Str I	雌	2326.67±177.81a	29.25±1.35a	1.44±0.11a	3.42±0.16a	3056.17±149.20b	32.02±2.50b	1.72±0.49a	3.35±0.56b
	Str I	雄	2137.33±159.47a	33.10±1.37a	1.37±0.08a	2.57±0.15ab	3724.50±212.75b	39.57±4.05a	1.73±0.14a	3.25±0.48b
	Str II	雌	511.67±45.62a	12.41±0.85a	1.67±0.13a	3.10±0.55a	606.17±38.76b	21.03±2.16b	1.38±0.33a	3.34±0.36a
	Str II	雄	411.33±35.81a	15.45±0.69a	1.34±0.15a	2.83±0.18a	765.83±102.88ab	22.24±3.06b	1.46±0.26a	2.90±0.37a
Sch	Sch I	雌	135.00±4.53a	13.46±0.54a	0.94±0.10a	2.29±0.16a	152.00±6.57c	18.03±0.43b	1.13±0.06a	2.36±0.10a
	Sch I	雄	101.50±3.53ab	12.81±0.48a	1.16±0.05a	2.54±0.17a	115.67±4.10bc	14.72±0.59a	1.08±0.05a	2.08±0.09a
	Sch II	雌	26.00±2.24a	7.63±0.41a	0.86±0.04a	2.23±0.09a	27.83±2.70a	13.06±0.54b	1.04±0.05b	2.26±0.10b
	Sch II	雄	22.50±0.76a	8.75±0.47a	1.12±0.03ab	2.76±0.10a	26.00±3.29a	9.09±0.32a	1.06±0.11ab	2.17±0.17a
Sco	Sco I	雌	51.83±2.68a	5.19±0.30a	—	5.65±0.21a	70.33±3.03c	6.05±0.38b	—	6.31±0.29a
	Sco I	雄	58.83±2.33a	6.33±0.31ab	—	6.16±1.37a	82.50±2.45b	4.34±0.23b	—	6.12±0.27a
	Sco II	雌	—	—	—	—	—	—	—	—
	Sco II	雄	—	—	—	—	8.17±2.41	5.03±0.30	—	11.64±0.53
Sst	Sst I	雌	50.83±3.40	9.52±1.54	3.01±0.65	—	—	—	—	—
	Sst I	雄	—	—	—	—	—	—	—	—
	Sst II	雌	—	—	—	—	66.00±3.29b	10.24±0.69b	3.89±0.20b	—
	Sst II	雄	47.83±2.30a	8.91±1.36a	2.72±0.64a	—	71.33±1.61b	9.38±0.10a	3.65±0.61a	—
	Sst III	雌	—	—	—	—	—	—	—	—
	Sst III	雄	—	—	—	—	4.75±0.48	11.94±0.57	3.17±0.25	—
Sau	Sau I	雌	—	—	—		36.17±3.29c	24.55±1.65b	—	—
	Sau I	雄	19.50±1.88a	17.95±2.18a	—	—	113.00±2.54b	15.84±0.42a	—	—
	Sau II	雌	86.17±3.74a	16.26±0.46a	—	—	21.33±3.14c	21.27±1.83b	—	—
	Sau II	雄	57.83±2.30b	17.58±0.95a	—	—	—	—	—	—
	Sau III	雌	156.83±6.36a	23.28±0.98a	—	—	86.00±3.29b	25.15±0.55b	—	—
	Sau III	雄	97.83±2.30a	21.64±0.89ab	—	—	101.17±1.58a	20.10±0.94bc	—	—
Sba	Sba	雌	26.83±2.73a	11.08±0.15a	1.48±0.05a	—	35.50±2.93b	21.97±1.54c	4.37±0.13b	—
Sba	Sba	雄	21.83±1.17ab	20.37±0.15b	1.38±0.09ab	—	27.00±2.19b	15.81±1.09c	1.70±0.07ab	—
Sin	Sin I	雌	1	10.63±0.18	29.01±0.37	—	1	41.67±0.88	16.30±0.15	—
	Sin I	雄	1	6.99±0.88	20.72±0.16	—	1	46.00±2.64	18.90±1.35	—
	Sin II	雌	9.67±0.20a	1.71±0.14a	1.57±0.32a	—	9.00±2.00a	2.01±0.15a	1.91±0.49a	—
	Sin II	雄	6.00±1.00a	2.06±0.06a	1.94±0.05a	—	11.33±2.03a	1.92±0.11a	1.76±0.10a	—
Ssq	Ssq I	雌	—	—	—	—	3.83±0.59	27.18±2.55	—	—
	Ssq I	雄	2.50±0.62	18.13±1.61	—	—	—	—	—	—
	Ssq II	雌	1083.33±70.58a	18.55±0.43a	—	—	1209.33±51.83b	22.21±0.37b	—	—
	Ssq II	雄	1018.33±33.70a	20.25±0.59ab	—	—	1520.00±51.38a	20.88±0.84b	—	—
Böhm	Bbr	雌	80.53±3.51a	7.02±1.21a	1.05±0.10a	—	65.67±3.56b	4.41±0.24a	1.27±0.06a	—
Böhm	Bbr	雄	61.67±5.30ab	8.82±1.83a	1.23±0.09a	—	85.67±2.85bc	7.65±0.82a	1.39±0.10a	—
Sma	Sma	雌	3.80±0.58	3.40±0.83	2.48±0.34	—	—	—	—	—
Sma	Sma	雄	—	—	—	—	—	—	—	—

感器类型		性别	茶丽细蛾				黑丽细蛾
感器类型		性别	数量	长度/μm	基部直径/μm	臼状窝直径/μm	数量	长度/μm	基部直径/μm	臼状窝直径/μm
Str	Str I	雌	2326.67±177.81a	29.25±1.35a	1.44±0.11a	3.42±0.16a	3056.17±149.20b	32.02±2.50b	1.72±0.49a	3.35±0.56b
	Str I	雄	2137.33±159.47a	33.10±1.37a	1.37±0.08a	2.57±0.15ab	3724.50±212.75b	39.57±4.05a	1.73±0.14a	3.25±0.48b
	Str II	雌	511.67±45.62a	12.41±0.85a	1.67±0.13a	3.10±0.55a	606.17±38.76b	21.03±2.16b	1.38±0.33a	3.34±0.36a
	Str II	雄	411.33±35.81a	15.45±0.69a	1.34±0.15a	2.83±0.18a	765.83±102.88ab	22.24±3.06b	1.46±0.26a	2.90±0.37a
Sch	Sch I	雌	135.00±4.53a	13.46±0.54a	0.94±0.10a	2.29±0.16a	152.00±6.57c	18.03±0.43b	1.13±0.06a	2.36±0.10a
	Sch I	雄	101.50±3.53ab	12.81±0.48a	1.16±0.05a	2.54±0.17a	115.67±4.10bc	14.72±0.59a	1.08±0.05a	2.08±0.09a
	Sch II	雌	26.00±2.24a	7.63±0.41a	0.86±0.04a	2.23±0.09a	27.83±2.70a	13.06±0.54b	1.04±0.05b	2.26±0.10b
	Sch II	雄	22.50±0.76a	8.75±0.47a	1.12±0.03ab	2.76±0.10a	26.00±3.29a	9.09±0.32a	1.06±0.11ab	2.17±0.17a
Sco	Sco I	雌	51.83±2.68a	5.19±0.30a	—	5.65±0.21a	70.33±3.03c	6.05±0.38b	—	6.31±0.29a
	Sco I	雄	58.83±2.33a	6.33±0.31ab	—	6.16±1.37a	82.50±2.45b	4.34±0.23b	—	6.12±0.27a
	Sco II	雌	—	—	—	—	—	—	—	—
	Sco II	雄	—	—	—	—	8.17±2.41	5.03±0.30	—	11.64±0.53
Sst	Sst I	雌	50.83±3.40	9.52±1.54	3.01±0.65	—	—	—	—	—
	Sst I	雄	—	—	—	—	—	—	—	—
	Sst II	雌	—	—	—	—	66.00±3.29b	10.24±0.69b	3.89±0.20b	—
	Sst II	雄	47.83±2.30a	8.91±1.36a	2.72±0.64a	—	71.33±1.61b	9.38±0.10a	3.65±0.61a	—
	Sst III	雌	—	—	—	—	—	—	—	—
	Sst III	雄	—	—	—	—	4.75±0.48	11.94±0.57	3.17±0.25	—
Sau	Sau I	雌	—	—	—		36.17±3.29c	24.55±1.65b	—	—
	Sau I	雄	19.50±1.88a	17.95±2.18a	—	—	113.00±2.54b	15.84±0.42a	—	—
	Sau II	雌	86.17±3.74a	16.26±0.46a	—	—	21.33±3.14c	21.27±1.83b	—	—
	Sau II	雄	57.83±2.30b	17.58±0.95a	—	—	—	—	—	—
	Sau III	雌	156.83±6.36a	23.28±0.98a	—	—	86.00±3.29b	25.15±0.55b	—	—
	Sau III	雄	97.83±2.30a	21.64±0.89ab	—	—	101.17±1.58a	20.10±0.94bc	—	—
Sba	Sba	雌	26.83±2.73a	11.08±0.15a	1.48±0.05a	—	35.50±2.93b	21.97±1.54c	4.37±0.13b	—
Sba	Sba	雄	21.83±1.17ab	20.37±0.15b	1.38±0.09ab	—	27.00±2.19b	15.81±1.09c	1.70±0.07ab	—
Sin	Sin I	雌	1	10.63±0.18	29.01±0.37	—	1	41.67±0.88	16.30±0.15	—
	Sin I	雄	1	6.99±0.88	20.72±0.16	—	1	46.00±2.64	18.90±1.35	—
	Sin II	雌	9.67±0.20a	1.71±0.14a	1.57±0.32a	—	9.00±2.00a	2.01±0.15a	1.91±0.49a	—
	Sin II	雄	6.00±1.00a	2.06±0.06a	1.94±0.05a	—	11.33±2.03a	1.92±0.11a	1.76±0.10a	—
Ssq	Ssq I	雌	—	—	—	—	3.83±0.59	27.18±2.55	—	—
	Ssq I	雄	2.50±0.62	18.13±1.61	—	—	—	—	—	—
	Ssq II	雌	1083.33±70.58a	18.55±0.43a	—	—	1209.33±51.83b	22.21±0.37b	—	—
	Ssq II	雄	1018.33±33.70a	20.25±0.59ab	—	—	1520.00±51.38a	20.88±0.84b	—	—
Böhm	Bbr	雌	80.53±3.51a	7.02±1.21a	1.05±0.10a	—	65.67±3.56b	4.41±0.24a	1.27±0.06a	—
Böhm	Bbr	雄	61.67±5.30ab	8.82±1.83a	1.23±0.09a	—	85.67±2.85bc	7.65±0.82a	1.39±0.10a	—
Sma	Sma	雌	3.80±0.58	3.40±0.83	2.48±0.34	—	—	—	—	—
Sma	Sma	雄	—	—	—	—	—	—	—	—
