杏壳木醋液对马铃薯瓢虫的非特异性作用

doi:10.11924/j.issn.1000-6850.casb2023-0387

中国农学通报 ›› 2024, Vol. 40 ›› Issue (13): 121-128.doi: 10.11924/j.issn.1000-6850.casb2023-0387

杏壳木醋液对马铃薯瓢虫的非特异性作用

甘杨广¹(), 叶乐夫², 李振宇¹, 王莉青¹, 池阳¹, 徐臻¹, 付雪¹()

¹ 黑龙江大学现代农业与生态环境学院，哈尔滨 150080
² 东北农业大学植物保护学院，哈尔滨 150030

收稿日期:2023-05-24 修回日期:2023-08-18 出版日期:2024-04-28 发布日期:2024-04-28
通讯作者:
付雪，1979年出生，黑龙江哈尔滨人，副教授，博士，主要从事农业昆虫与害虫防治研究工作。通信地址：150080 黑龙江省哈尔滨市南岗区学府路74号黑龙江大学，E-mail：2008003@hlju.edu.cn。
作者简介:
甘杨广，1997年出生，广西玉林人，硕士，研究方向：农业昆虫与害虫防治。通信地址：150080 黑龙江省哈尔滨市南岗区学府路74号黑龙江大学，E-mail：gtrios@163.com。
基金资助:
黑龙江省省属高等学校基本科研业务费项目“木醋液对内共生菌介导的桃蚜抗药性的影响机制研究”(2022-KYYWF-1068)

Non-Specific Effects of Apricot Shell Wood Vinegar Solution on Henosepilachna vigintioctopunctata

GAN Yangguang¹(), YE Lefu², LI Zhenyu¹, WANG Liqing¹, CHI Yang¹, XU Zhen¹, FU Xue¹()

¹ College of Modern Agriculture and Ecological Environment, Heilongjiang University, Harbin 150080
² College of Plant Protection, Northeast Agricultural University, Harbin 150030

Received:2023-05-24 Revised:2023-08-18 Published:2024-04-28 Online:2024-04-28

摘要/Abstract

摘要：

探究杏壳木醋液对马铃薯瓢虫的生长抑制、拒食活性以及驱避活性影响，明确杏壳木醋液对马铃薯瓢虫的非特异性作用，为马铃薯瓢虫绿色防控和木醋液的害虫防治应用提供理论依据。用杏壳木醋液不同浓度处理的龙葵叶片喂食马铃薯瓢虫，测定不同浓度处理在各时间段4龄幼虫的体重增长量、成虫和幼虫的非选择性和选择性取食量以及行为选择情况，并分析不同浓度杏壳木醋液对马铃薯瓢虫的增重抑制、拒食活性、驱避活性等影响。结果表明，4龄幼虫的体重增加、成虫和幼虫的非选择性和选择性取食量以及行为选择均显著受到杏壳木醋液的影响，其中杏壳木醋液在48 h时4龄幼虫体重增长抑制率最高达到83%；4龄幼虫和成虫的最高非选择性拒食率分别为92%和82%；最高选择性拒食率分别为87%和78%；马铃薯瓢虫幼虫和成虫在四臂嗅觉仪中均表现出了极显著的驱避作用，幼虫的最高驱避指数为0.67，成虫为0.95。杏壳木醋液对马铃薯瓢虫有显著的增重抑制、拒食活性和驱避活性，杏壳木醋液浓度对马铃薯瓢虫还有显著的非特异性作用。

关键词: 马铃薯瓢虫, 木醋液, 生长抑制, 拒食作用, 驱避作用, 四臂嗅觉仪

Abstract:

To investigate the growth inhibition, anti-feeding and repellent activity of apricot shell wood vinegar on the Henosepilachna vigintioctopunctata, to clarify the non-specific effect of apricot shell wood vinegar on the Mots, and to provide a theoretical basis for the application of the Mots’ green prevention and control and the application of wood vinegar for pest control. The Mots were fed with leaves of Solanum nigrum treated with different concentrations of apricot shell wood vinegar solution, and the body weight gain of 4^th instar larvae, non-selective anti-feeding and selective anti-feeding of adults and larvae as well as behavioral choices of different concentrations of apricot shell wood vinegar solution were measured in each period, and the effects of different concentrations of apricot shell wood vinegar solution on the weight gain inhibition, anti-feeding and repellency were analyzed, respectively. The results showed that, the weight gain of 4^th instar larvae, non-selective anti-feeding and selective anti-feeding of adults and larvae, and behavioral choice were all significantly affected by apricot shell wood vinegar solution, among which the weight gain inhibition of 4^th instar larvae by apricot shell wood vinegar solution reached 83% at 48 h. The highest non-selective anti-feeding rates were 92% and 82% for 4^th instar larvae and adults, respectively; the highest selective anti-feeding rates were 87% and 78% for 4^th instar larvae and adults, respectively; the Mots larvae and adults in the four-quadrant olfactometer showed highly significant repellent effect, with the highest repellent index of 0.67 for larvae and 0.95 for adults. It’s shown that apricot shell wood vinegar had significant weight gain inhibition, anti-feeding and repellent activity on the Mots. The concentration of apricot shell wood vinegar also had significant non-specific effects on the Mots.

Key words: Henosepilachna vigintioctopunctata, wood vinegar, growth inhibition, anti-feeding effect, repellent effect, four-quadrant olfactometer

甘杨广, 叶乐夫, 李振宇, 王莉青, 池阳, 徐臻, 付雪. 杏壳木醋液对马铃薯瓢虫的非特异性作用[J]. 中国农学通报, 2024, 40(13): 121-128.

GAN Yangguang, YE Lefu, LI Zhenyu, WANG Liqing, CHI Yang, XU Zhen, FU Xue. Non-Specific Effects of Apricot Shell Wood Vinegar Solution on Henosepilachna vigintioctopunctata[J]. Chinese Agricultural Science Bulletin, 2024, 40(13): 121-128.

图/表 10

参考文献 27

[1]	郭木娟, 陈诗敏, 庾家琪, 等. 马铃薯瓢虫与茄二十八星瓢虫SCAR标记的建立及应用[J]. 环境昆虫学报, 2020, 42(2):434-440.
[2]	李保同, 闫超, 平新亮, 等. 茄二十八星瓢虫对雷公藤和曼陀罗提取物的敏感性[J]. 中国生态农业学报, 2012, 20(4):495-500.
[3]	符真, 胡兵, 涂小云, 等. 茄二十八星瓢虫产卵观察[J]. 安徽农业科学, 2009, 37(33):16423-16499.
[4]	KOVALENKO T K, PRONYUSHKINA A S. Potato protection against potato ladybird Henosepilachna vigintioctopunctata (Coleoptera, Coccinellidae)[J]. Siberian herald of agricultural science, 2021, 51(1):67-73.
[5]	王波. 苏云金芽孢杆菌对茄二十八星瓢虫毒性测定[J]. 陕西农业科学, 2014, 60(7):4-5,29.
[6]	王婧瑜, 王洪萱, 王在凌, 等. 茄二十八星瓢虫成虫对不同寄主植物的选择性研究[J]. 长江大学学报(自科版), 2018, 15(22):1-4,101.
[7]	丁新华, 阿尔孜姑丽·肉孜, 纪利, 等. 马铃薯瓢虫的发生与危害[J]. 新疆农业科学, 2022, 59(4):983-989. doi: 10.6048/j.issn.1001-4330.2022.04.024
[8]	WU Q M, ZHANG S Y, HOU B X, et al. Study on the preparation of wood vinegar from biomass residues by carbonization process[J]. Bioresource technology, 2015, 179(12):98-103. doi: 10.1016/j.biortech.2014.12.026 URL
[9]	赵淑蘅, 李卓洁, 刘晓锋, 等. 秸秆木醋液的制备及应用研究进展[J]. 河南农业科学, 2022, 51(1):1-10.
[10]	MA X, QIN W, ZHANG S, et al. Isolation and bioactivities of organic acids and phenols from walnut shell pyroligneous acid[J]. Journal of analytical & applied pyrolysis, 2011, 91(2):338-343.
[11]	LIU X, WANG J, FENG X, et al. Wood vinegar resulting from the pyrolysis of apple tree branches for annual bluegrass control[J]. Industrial crops and products, 2021, 174(1):114193-114204. doi: 10.1016/j.indcrop.2021.114193 URL
[12]	CHEN Y H, LI Y F, WEI H, et al. Inhibition efficiency of wood vinegar on grey mould of table grapes[J]. Food bioscience, 2020, 38(12):100755. doi: 10.1016/j.fbio.2020.100755 URL
[13]	WU S Y, WU Y Q, GAO J S, et al. The effect of wood vinegar on hydrothermal liquefaction of cotton stalk under CO atmosphere[J]. Energy sources, 2013, 36(4):411-417.
[14]	HAGNER M, TIILIKKALA K, LINDQVIST I, et al. Performance of liquids from slow pyrolysis and hydrothermal carbonization in plant protection[J]. Waste and biomass valorization, 2020, 11(3):1005-1016. doi: 10.1007/s12649-018-00545-1
[15]	MOHAMMAD H, KHALIL T, EHSSAN T, et al. Effects of pyroligneous acid on life history and physiology of two pyralid pests of stored products[J]. Journal of stored products research, 2022, 97(10):101971-101982. doi: 10.1016/j.jspr.2022.101971 URL
[16]	WANG P, MALIANG H, WANG C, et al. Bamboo charcoal by-products as sources of new insecticide and acaricide[J]. Industrial crops & products, 2015, 77(23):575-581.
[17]	马娟, 王容燕, 高波, 等. 木醋液与噻唑膦联合应用对甘薯茎线虫病防治效果[J]. 农药, 2022, 61(9):682-686.
[18]	INDRIATI G, SAMSUDIN, SUSILAWATI, et al. The potency of coconut shell wood vinegar and essential oils as botanical insecticides to control Hypothenemus hampei(Coleoptera: Curculionidae)[J]. Earth and environmental science, 2021, 762(1):12057.
[19]	李小艳, 亓东明, 孙成仁, 等. 半夏乙醇提取物对茄二十八星瓢虫的拒食活性研究初报[J]. 西华师范大学学报(自然科学版), 2008(1):59-62.
[20]	孙琳琳, 张璇, 石佳敏, 等. 基于四臂嗅觉仪内轨迹跟踪的昆虫嗅觉行为分析体系[J]. 昆虫学报, 2021, 64(7):828-839.
[21]	钟平生, 梁广文, 曾玲, 等. 非嗜食植物次生化合物对褐稻虱试验种群的控制作用[J]. 仲恺农业技术学院学报, 2004, 17(2):13-18
[22]	CHAPMAN R F. Contact chemoreception in feeding by phytophagous insects[J]. Annual review of entomology, 2003, 48(1):455-484. doi: 10.1146/ento.2003.48.issue-1 URL
[23]	张钟宁, 方宇凌. 昆虫拒食剂蓼二醛的合成及其对害虫的拒食活性[J]. 昆虫知识, 2001(3):207-210.
[24]	刘淑娟. 植物次生代谢物的分布及其应用[J]. 泰山学院学报, 2003(6):91-94.
[25]	金党琴. 银杏酚酸与印楝素及其复合混配剂对小菜蛾的毒效[J]. 江苏农业科学, 2017, 45(4):76-77.
[26]	DEWI R, HASTUTI N, NURAENI Y, et al. Utilization of wood vinegar as plant based insecticide in mulberry (Morus sp.)[J]. Materials science and engineering, 2020, 935(1):12027.
[27]	RAHMAT B, PANGESTI D, NATAWIJAYAD, et al. Generation of wood-waste vinegar and its effectiveness as a plant growth regulator and pest insect repellent[J]. Bioresources, 2014, 9(4):6350-6360.

浓度/(mL/L)	24 h		48 h
浓度/(mL/L)	取食面积/cm²	非选择性拒食/%	取食面积/cm²	非选择性拒食/%
CK	3.02±0.28a	0d	5.87±0.45a	0d
1	2.15±0.21b	28.89±7.05c	4.06±0.39b	30.89±6.67c
2	1.63±0.15c	45.78±5.92b	2.94±0.41c	49.95±6.88b
5	1.32±0.16c	56.18±5.19b	2.32±0.34c	60.53±5.74b
10	0.66±0.08d	78.11±2.76a	1.30±0.17d	77.85±2.84a
20	0.43±0.12d	85.65±3.84a	0.71±0.13d	87.87±2.20a
50	0.42±0.10d	86.06±3.38a	0.79±0.22d	86.58±3.71a
100	0.28±0.06d	90.62±1.94a	0.48±0.09d	91.90±1.61a
回归方程	y=0.9432x+4.5908		y=0.9326x+4.6690
拒食中浓度AFC₅₀/(mL/L)	2.72		2.26
R²	0.9370		0.9371

浓度/(mL/L)	24 h		48 h
浓度/(mL/L)	取食面积/cm²	非选择性拒食/%	取食面积/cm²	非选择性拒食/%
CK	3.02±0.28a	0d	5.87±0.45a	0d
1	2.15±0.21b	28.89±7.05c	4.06±0.39b	30.89±6.67c
2	1.63±0.15c	45.78±5.92b	2.94±0.41c	49.95±6.88b
5	1.32±0.16c	56.18±5.19b	2.32±0.34c	60.53±5.74b
10	0.66±0.08d	78.11±2.76a	1.30±0.17d	77.85±2.84a
20	0.43±0.12d	85.65±3.84a	0.71±0.13d	87.87±2.20a
50	0.42±0.10d	86.06±3.38a	0.79±0.22d	86.58±3.71a
100	0.28±0.06d	90.62±1.94a	0.48±0.09d	91.90±1.61a
回归方程	y=0.9432x+4.5908		y=0.9326x+4.6690
拒食中浓度AFC₅₀/(mL/L)	2.72		2.26
R²	0.9370		0.9371

浓度/(mL/L)	24 h		48 h
浓度/(mL/L)	取食面积/cm²	非选择性拒食/%	取食面积/cm²	非选择性拒食/%
CK	8.09±0.38a	0f	15.02±0.59a	0e
1	5.64±0.33b	30.30±4.08e	10.17±0.45b	32.28±3.05d
2	5.33±0.20b	34.16±2.52e	9.54±0.38b	36.47±2.56d
5	4.47±0.30c	44.75±3.66d	7.71±0.58c	48.70±3.87c
10	2.94±0.22d	63.60±2.76c	5.10±0.41d	66.07±2.73b
20	2.61±0.18de	67.71±2.20bc	4.40±0.34d	70.73±2.27b
50	2.06±0.23ef	74.59±2.90ab	3.01±0.40e	79.93±2.65a
100	1.62±0.20f	80.02±2.50a	2.72±0.49e	81.91±2.65a
回归方程	y=0.7232x+4.4567		y=0.7509x+4.5166
拒食中浓度AFC₅₀/(mL/L)	5.64		4.4
R²	0.9694		0.9718

浓度/(mL/L)	24 h		48 h
浓度/(mL/L)	取食面积/cm²	非选择性拒食/%	取食面积/cm²	非选择性拒食/%
CK	8.09±0.38a	0f	15.02±0.59a	0e
1	5.64±0.33b	30.30±4.08e	10.17±0.45b	32.28±3.05d
2	5.33±0.20b	34.16±2.52e	9.54±0.38b	36.47±2.56d
5	4.47±0.30c	44.75±3.66d	7.71±0.58c	48.70±3.87c
10	2.94±0.22d	63.60±2.76c	5.10±0.41d	66.07±2.73b
20	2.61±0.18de	67.71±2.20bc	4.40±0.34d	70.73±2.27b
50	2.06±0.23ef	74.59±2.90ab	3.01±0.40e	79.93±2.65a
100	1.62±0.20f	80.02±2.50a	2.72±0.49e	81.91±2.65a
回归方程	y=0.7232x+4.4567		y=0.7509x+4.5166
拒食中浓度AFC₅₀/(mL/L)	5.64		4.4
R²	0.9694		0.9718

浓度/(mL/L)	处理	24 h			48 h
浓度/(mL/L)	处理	取食面积/cm²		选择性拒食率/%	取食面积/cm²		选择性拒食率/%
1	C	3.30±0.25^**		35.75±5.26e	6.16±0.38^**		34.51±2.73e
1	T	1.56±0.16		35.75±5.26e	2.99±0.19		34.51±2.73e
2	C	2.92±0.21^**		39.38±5.06de	4.88±0.30^**		38.85±4.53e
2	T	1.30±0.17		39.38±5.06de	2.19±0.22		38.85±4.53e
5	C	2.44±0.25^**		49.84±4.31d	3.91±0.24^**		54.00±2.55d
5	T	0.83±0.12		49.84±4.31d	1.18±0.11		54.00±2.55d
10	C	2.25±0.24^**		63.97±3.46c	3.22±0.26^**		67.54±2.05c
10	T	0.50±0.09		63.97±3.46c	0.64±0.09		67.54±2.05c
20	C	1.53±0.23^**		72.86±2.92bc	2.66±0.27^**		77.22±2.20b
20	T	0.24±0.04		72.86±2.92bc	0.36±0.06		77.22±2.20b
50	C	1.54±0.17^**		83.33±1.72ab	2.66±0.27^**		83.40±2.01ab
50	T	0.15±0.03		83.33±1.72ab	0.25±0.05		83.40±2.01ab
100	C	1.54±0.15^**		85.26±1.55a	2.52±0.28^**		86.56±2.20a
100	T	0.12±0.01		85.26±1.55a	0.17±0.02		86.56±2.20a
回归方程			y=0.7794x+4.5558			y=0.8251x+4.5458
拒食中浓AFC₅₀/(mL/L)			3.72			3.55
R²			0.9821			0.9751
