中国农学通报 ›› 2024, Vol. 40 ›› Issue (13): 140-145.doi: 10.11924/j.issn.1000-6850.casb2023-0388

• 农业信息·科技教育 • 上一篇    下一篇

基于R语言的AMMI模型和GGE双标图在大豆区试中的应用评价

张恺东1,2(), 张凡巧3, 董博2(), 段佳霖4,5(), 陈光荣2, 王立明2, 杨如萍2

  1. 1 甘肃省农业科学院榆中高寒农业试验站/甘肃绿星农业科技有限责任公司，兰州 730070
    2 甘肃省农业科学院旱地农业研究所，兰州 730700
    3 通渭县林业和草原服务中心，甘肃通渭 743300
    4 甘肃农业大学资源与环境学院，兰州 730070
    5 甘肃省寒旱生态农业研究所，兰州 730070
  • 收稿日期:2023-05-24 修回日期:2023-12-27 出版日期:2024-04-28 发布日期:2024-04-28
  • 通讯作者:
    董博，男，1981年出生，山东东阿人，研究员，博士，研究方向：农田水肥调控、数字农业工程。通信地址：730070 甘肃省兰州市安宁区农科院新村1号旱农所，Tel：0931-7611161，E-mail：。
    段佳霖，女，1998年出生，山西临汾人，硕士，研究方向：农业资源利用。通信地址：730070 甘肃省兰州市安宁区农科院新村1号旱农所，Tel：0931-7611161，E-mail：。
  • 作者简介:

    张恺东，男，1992年出生，甘肃靖远人，学士，研究方向：大豆资源利用与开发。通信地址：730070 甘肃省兰州市安宁区农科院新村1号旱农所，Tel：0931-7614854，E-mail：。

  • 基金资助:
    国家产业技术体系“兰州大豆综合试验站建设”(CARS-04-CES25); 甘肃省农业科学院重点研发项目“优质牧草大豆种质资源创制与应用”(2020GAAS11); 甘肃省农业科学院重点研发项目“饲草大豆耐寒性鉴定及配套栽培技术研究”(2021GAAS16); 甘肃省农业科学院重点研发项目“玉米-大豆带状复合种植模式下大豆耐荫性鉴定与应用”(2022GAAS10); 甘肃省重点研发计划项目“引洮定西灌区节水生态调蓄设施及蔬菜节水补灌技术研究与示范”(20YF8NA107)

Application Evaluation of AMMI Model and GGE Biplot Based on R Language in Soybean Regional Test

ZHANG Kaidong1,2(), ZHANG Fanqiao3, DONG Bo2(), DUAN Jialin4,5(), CHEN Guangrong2, WANG Liming2, YANG Ruping2

  1. 1 Yuzhong Alpine Agricultural Experiment Station, Gansu Academy of Agricultural Sciences/Gansu Greenstar Agro-tech Co. LTD., Lanzhou 730100
    2 Dryland Agriculture Institute, Gansu Academy of Agricultural Sciences, Lanzhou 730070
    3 Forestry and Grassland Service Center of Tongwei County, Tongwei, Gansu 743300
    4 College of Resources and Environmental Sciences, Gansu Agricultural University, Lanzhou 730070
    5 Gansu Province Institute of Cold-Arid and Ecological Agriculture, Lanzhou 730070
  • Received:2023-05-24 Revised:2023-12-27 Published:2024-04-28 Online:2024-04-28

RichHTML

7

PDF (PC)

273

摘要：

为提高甘肃省大豆品种的选育和应用效率，利用大豆区域试验数据，从基因型与环境的互作分析出发，对甘肃省大豆新品种的稳定性、适应性以及各试点的鉴别力进行全面评估。本研究采用AMMI模型与GGE双标图相结合的方法对甘肃省9个大豆品种在5个试验点的产量进行分析，结果表明，AMMI模型中主成分值(IPCA1、IPCA2)占总变异平方和的95%；其中‘中黄318’属于高产稳产性品种，而‘陇黄3号’和‘铁丰31’虽然产量较高，但其稳定性中等，适合在特定区域栽培。在5个试验点中，凉州分辨力最强，镇原分辨力较弱。综合运用AMMI模型和GGE双标图法，能够更准确直观地反映各品种生产力、稳定性和适应能力，以及在不同试验区域的分辨能力和代表性。

关键词: AMMI模型, GGE双标图, 大豆, 稳定性, 适应性

Abstract:

To improve the selection and application efficiency of soybean varieties in Gansu Province, data from soybean regional trials were used to comprehensively assess the stability and adaptability of new soybean varieties in Gansu Province and the discrimination power of each pilot site in terms of the interaction analysis between genotype and environment. This paper used the AMMI model combined with GGE double-labeled plots to analyze the yields of nine soybean varieties in Gansu Province at five trial sites. The results showed that the principal component values (IPCA1 and IPCA2) in the AMMI model accounted for 95% of the sum of squares of the total variation; among them, ‘Zhonghuang 318’ was a high-yield and stable variety, while ‘Longhuang 3’ and ‘Tiefeng 31’ had higher yields but moderate stability, making them only suitable for cultivation in specific areas. Among the five trial sites, Liangzhou had the strongest discrimination power and Zhenyuan was weaker. The combined use of the AMMI model and the GGE double-labeled map method can more accurately and intuitively reflect the productivity, stability and adaptability of each variety as well as the discrimination power and representativeness of each trial site.

Key words: AMMI model, GGE biplots, soybean, stability, adaptability
