The Accumulation of Five Heavy Metals in Different Genotypes of Brassica juncea

doi:10.11924/j.issn.1000-6850.casb2020-0757

Abstract

Abstract:

The study aims to investigate the accumulation difference of five heavy metals: cadmium (Cd), arsenic (As), lead (Pb), mercury (Hg) and chromium (Cr) in different genotypes of brassica juncea, and to provide guidance on the production safety of brassica juncea in areas with complex contamination of heavy metals. Combining the heavy metal biological concentration factor and transfer factor with the single-factor contamination index method, as well as the Nemero integrated contamination method, the responses of nine different genotypes of brassica juncea to the five heavy metals were investigated in pot experiments to comprehensively evaluate the production safety of brassica juncea in heavy metal contaminated areas. The results show that Brassica juncea has strong ability to transfer heavy metals from stem to leaf, and heavy metals are mainly accumulated in the roots and leaves of brassica juncea. The individual contamination index of heavy metal Cd in different parts of brassica juncea is generally high and has large varietal difference. The contamination indexes between Pb, As, Hg and Cr show similar trend, and the differences between species and parts are not obvious. Among the varieties tested, ‘Wusiqingpeilan’, ‘Cuinengercai’, ‘Tedabangcai’ and ‘Kangresijitianzhujie’ are better brassica juncea varieties with ower heavy metal accumulation capacity. The accumulation of heavy metal in brassica juncea is related to genotype and heavy metal species, and it is feasible to select brassica juncea varieties with low accumulation of heavy metals which can be used for planting in heavy metal contaminated fields.

Key words: Brassica juncea, heavy metal, genotype, cumulative difference, biological concentration factor, transfer factor, safety assessment

CLC Number:

S637

Mi Baobin, Liu Biqiong, Dai Xiongze, Xiao Wei, Zhang Zhuqing, Zhou Huoqiang, Wang Duanhua. The Accumulation of Five Heavy Metals in Different Genotypes of Brassica juncea[J]. Chinese Agricultural Science Bulletin, 2021, 37(26): 40-49.

Figures/Tables 12

References 34

[1]	Sultana M S, Jolly Y N, Yeasmin S, et al. Chapter 12-Transfer of Heavy Metals and Radionuclides from Soil to Vegetables and Plants in Bangladesh[M].San DiegoAcademic Press, 2015:331-366.
[2]	Rizwan M, Ali S, Abbas T, et al. Cadmium minimization in wheat: A critical review[J]. Ecotoxicol Environ Saf, 2016, 130:43-53. doi: 10.1016/j.ecoenv.2016.04.001 URL
[3]	Xie L, Pengfei H, Yu C, et al. Effect of combined application of lead, cadmium, chromium and copper on grain, leaf and stem heavy metal contents at different growth stages in rice[J]. Ecotoxicology & Environmental Safety, 2018, 162:71-76.
[4]	Niazi N K, Bishop T F A, Singh B. Evaluation of Spatial Variability of Soil Arsenic Adjacent to a Disused Cattle-Dip Site, Using Model-Based Geostatistics[J]. Environmental Science & Technology, 2011, 45(24):10463-10470. doi: 10.1021/es201726c URL
[5]	Mao C, Song Y, Chen L, et al. Human health risks of heavy metals in paddy rice based on transfer characteristics of heavy metals from soil to rice[J]. CATENA, 2019, 175:339-348. doi: 10.1016/j.catena.2018.12.029 URL
[6]	Yang L, Huang B, Mao M, et al. Trace metal accumulation in soil and their phytoavailability as affected by greenhouse types in north China[J]. Environmental Science & Pollution Research, 2015, 22(9):6679-6686.
[7]	Xu L, Lu A, Wang J, et al. Accumulation status, sources and phytoavailability of metals in greenhouse vegetable production systems in Beijing, China[J]. Ecotoxicology & Environmental Safety, 2015, 122(DEC.):214-220.
[8]	Rai P K, Lee S S, Zhang M, et al. Heavy metals in food crops: Health risks, fate, mechanisms, and management[J]. Environment International, 2019, 125:365-385. doi: 10.1016/j.envint.2019.01.067 URL
[9]	Ali H, Khan E, Sajad M A. Phytoremediation of heavy metals—Concepts and applications[J]. Chemosphere, 2013, 91(7):869-881. doi: 10.1016/j.chemosphere.2013.01.075 URL
[10]	Lasat M M. Phytoextraction of toxic metals: a review of biological mechanisms[J]. J Environ Qual, 2002, 31(1):109-120.
[11]	Mi B, Liu F, Xie L, et al. Evaluation of the uptake capacities of heavy metals in Chinese cabbage[J]. Ecotoxicology and Environmental Safety, 2019, 171:511-517. doi: 10.1016/j.ecoenv.2019.01.022 URL
[12]	Wang X, Shi Y, Chen X, et al. Screening of Cd-safe genotypes of Chinese cabbage in field condition and Cd accumulation in relation to organic acids in two typical genotypes under long-term Cd stress[J]. Environmental Science & Pollution Research International, 2015, 22(21):16590-16599.
[13]	Wang L, Xu Y, Sun Y, et al. Identification of pakchoi cultivars with low cadmium accumulation and soil factors that affect their cadmium uptake and translocation[J]. Frontiers of Environmental Science & Engineering, 2014, 8(6):877-887.
[14]	Liu B, Wu F, Dai X, et al. Variations of Cadmium Accumulation and Translocation in Different Pakchoi Cultivars and Screening for Cd-Pollution-Safe Cultivars Using Cluster Analysis[J]. Polish Journal of Environmental Studies, 2019, 28(4):2215-2222. doi: 10.15244/pjoes/89980 URL
[15]	刘峰, 弭宝彬, 魏瑞敏, 等. 基于聚类分析法筛选低镉累积辣椒品种[J]. 园艺学报, 2017, 44(5):979-986.
[16]	Xin J, Huang B, Liu A, et al. Identification of hot pepper cultivars containing low Cd levels after growing on contaminated soil: uptake and redistribution to the edible plant parts[J]. Plant & Soil, 2013, 373(1-2):415-425.
[17]	Li X, Zhou Q, Wei S, et al. Identification of cadmium-excluding welsh onion (Allium fistulosum L.) cultivars and their mechanisms of low cadmium accumulation[J]. Environmental Science & Pollution Research, 2012, 19(5):1773-1780.
[18]	He B Y, Ling L, Zhang L, et al. Cultivar-specific differences in heavy metal (Cd, Cr, Cu, Pb, and Zn) concentrations in water spinach (Ipomoea aquatic‘Forsk’) grown on metal-contaminated soil[J]. Plant & Soil, 2015, 386(1-2):251-262.
[19]	Hu W, Huang B, Tian K, et al. Heavy metals in intensive greenhouse vegetable production systems along Yellow Sea of China: Levels, transfer and health risk[J]. Chemosphere, 2017, 167:82-90. doi: 10.1016/j.chemosphere.2016.09.122 URL
[20]	文典. 珠三角地区土壤中5种重金属在叶菜类蔬菜中的累积特征及其环境安全临界值[D]. 武汉:华中农业大学, 2012.
[21]	杨庆娥, 任振江, 高然. 污水灌溉对土壤和蔬菜中重金属积累和分布影响研究[J]. 中国农村水利水电 2007(5):74-75.
[22]	Yuan Y, Xiang M, Liu C, et al. Chronic impact of an accidental wastewater spill from a smelter, China: A study of health risk of heavy metal(loid)s via vegetable intake[J]. Ecotoxicol Environ Saf, 2019, 182:109401. doi: 10.1016/j.ecoenv.2019.109401 URL
[23]	弭宝彬, 刘碧琼, 周火强, 等. 不同萝卜品种对5种重金属响应规律研究[J]. 核农学报, 2020, 34(5):1119-1127.
[24]	杜俊杰, 李娜, 吴永宁, 等. 蔬菜对重金属的积累差异及低积累蔬菜的研究进展[J]. 农业环境科学学报, 2019, 38(6):1193-1201.
[25]	Tapash, Dasgupta, Shahid, A., et al. An arsenate tolerance gene on chromosome 6 of rice[J]. New Phytologist, 2004, 163(1):45-49. doi: 10.1111/j.1469-8137.2004.01109.x pmid: 33873777
[26]	Bezerril Fontenele N M, Oliveira Otoch M D L, Gomes-Rochette N F, et al. Effect of lead on physiological and antioxidant responses in two Vigna unguiculata cultivars differing in Pb-accumulation[J]. Chemosphere, 2017, 176(JUN.):397-404. doi: 10.1016/j.chemosphere.2017.02.072 URL
[27]	Xin J, Huang B. Subcellular Distribution and Chemical Forms of Cadmium in Two Hot Pepper Cultivars Differing in Cadmium Accumulation[J]. Journal of Agricultural & Food Chemistry, 2014, 62(2):508-515.
[28]	Xin J, Huang B, Dai H, et al. Roles of rhizosphere and root-derived organic acids in Cd accumulation by two hot pepper cultivars[J]. Environmental Science & Pollution Research, 2015, 22(8):6254-6261.
[29]	Alexander P D, Alloway B J, Dourado A M. Genotypic variations in the accumulation of Cd, Cu, Pb and Zn exhibited by six commonly grown vegetables[J]. Environmental Pollution, 2006, 144(3):736-745. pmid: 16647172
[30]	Fang H, Li W, Tu S, et al. Differences in cadmium absorption by 71 leaf vegetable varieties from different families and genera and their health risk assessment[J]. Ecotoxicol Environ Saf, 2019, 184:109593. doi: 10.1016/j.ecoenv.2019.109593 URL
[31]	刘维涛, 周启星, 孙约兵, 等. 大白菜(Brassica pekinensis L.)对镉富集基因型差异的研究[J]. 应用基础与工程科学学报, 2010, 18(2):226-235.
[32]	王若男, 乜兰春, 张双双, 等. 植物抗重金属胁迫研究进展[J]. 园艺学报, 2019, 46(1):162-175
[33]	Wang G, Zhang S, Zhong Q, et al. Feasibility of Chinese cabbage (Brassica bara) and lettuce (Lactuca sativa) cultivation in heavily metals -contaminated soil after washing with biodegradable chelators[J]. Journal of Cleaner Production, 2018, 197:479-490. doi: 10.1016/j.jclepro.2018.06.225 URL
[34]	Shahid M, Dumat C, Khalid S, et al. Foliar heavy metal uptake, toxicity and detoxification in plants: A comparison of foliar and root metal uptake[J]. J Hazard Mater, 2017, 325:36-58. doi: 10.1016/j.jhazmat.2016.11.063 URL

品名	类型	编号	品名	类型	编号	品名	类型	编号
五四青丕蓝	根芥	J1	特大棒菜	茎芥	J4	大头菜	榨菜	J7
细叶雪里蕻	叶芥	J2	抗热四季甜竹芥	茎芥	J5	三胞心青菜	叶芥	J8
脆嫩儿菜	茎芥	J3	香港白花柳叶芥兰	叶芥	J6	佳园菊花菜	叶芥	J9

品名	类型	编号	品名	类型	编号	品名	类型	编号
五四青丕蓝	根芥	J1	特大棒菜	茎芥	J4	大头菜	榨菜	J7
细叶雪里蕻	叶芥	J2	抗热四季甜竹芥	茎芥	J5	三胞心青菜	叶芥	J8
脆嫩儿菜	茎芥	J3	香港白花柳叶芥兰	叶芥	J6	佳园菊花菜	叶芥	J9

重金属类型	镉Cd	铅Pb	铬Cr	汞Hg	砷As
测试土壤	3.478	131.7	63.9	0.26	79.0
国标限量(GB 15618—2008)	0.25	50	120	0.20	35

重金属类型	镉Cd	铅Pb	铬Cr	汞Hg	砷As
测试土壤	3.478	131.7	63.9	0.26	79.0
国标限量(GB 15618—2008)	0.25	50	120	0.20	35

组织部位	镉Cd	铅Pb	铬Cr	汞Hg	砷As
芥菜根	0.05	0.10	0.50	0.01	0.50
芥菜茎	0.10	0.10	0.50	0.01	0.50
芥菜叶	0.20	0.30	0.50	0.01	0.50
