柠檬叶片溃疡病菌的分离鉴定及室内防治药剂筛选

doi:10.11924/j.issn.1000-6850.casb2020-0628

摘要/Abstract

摘要：

为了明确湛江地区柑橘溃疡病的病原类型并筛选出高效的防治药剂。以柠檬病叶为材料,用组织分离法对病样进行病原菌分离鉴定后,通过抑菌圈法测定了5种常用药剂对该病原菌的室内毒力。典型菌株zlm1908在NA培养基上菌落呈蜡黄色,圆形,全缘,有光泽,微隆起,黏稠,回接健康柠檬叶片后能产生明显的溃疡病斑,结合生理生化反应特点和特异性引物扩增序列分析确定菌株zlm1908为柑橘黄单胞柑橘亚种(Xanthomonas citri subsp.citri,Xcc)。5种药剂对菌株zlm1908的EC₅₀值分别为18.45 g/L、14.99 g/L、5.28 g/L、14.60 g/L和32.81 g/L。从EC₅₀的大小可以看出5种杀菌剂中枯草芽孢杆菌的抑制作用最强,其次为中生菌素,碱式硫酸铜和氢氧化铜,氯溴异氰尿酸抑制作用最弱。

关键词: 柑橘溃疡病菌, 病原鉴定, 杀菌剂, 毒力测定

Abstract:

The purpose of this study is to identify the pathogen types of citrus bacterial canker disease in Zhanjiang area and screen effective bactericides. Lemon leaves were used as materials, and the strains were isolated and identified by tissue separation. The indoor toxicity of five bactericides to this pathogen was determined by inhibition zone test. The colony morphology of classic strain zlm1908 on nutrient agar medium (NA) was wax yellow, circular, entire, glistening, convex and mucoid. Citrus canker disease symptoms appeared obviously after reinoculating healthy lemon leaves. The strain zlm1908 was identified as Xanthomonas citri subsp. citri (Xcc) by physiological and biochemical reaction, specific primer amplification and sequence analysis. The EC₅₀ of five bactericides was 18.45 g/L, 14.99 g/L, 5.28 g/L, 14.60 g/L and 32.81 g/L, respectively. According to the analysis of EC₅₀ value, the inhibiting effect of Bacillus subtilis is the strongest among the five bactericides, followed by zhongshengmycin, copper dihydroxosulphate, copper hydroxide, while chlorobromoisocyanurate has the least inhibiting effect.

Key words: Xanthomonas citri subsp. citri (Xcc), pathogen identification, bactericide, toxicity test

中图分类号:

李亚, 蔡永军, 余沁涵, 孔少连, 周晓晴, 张颖荷. 柠檬叶片溃疡病菌的分离鉴定及室内防治药剂筛选[J]. 中国农学通报, 2021, 37(24): 146-153.

Li Ya, Cai Yongjun, Yu Qinhan, Kong Shaolian, Zhou Xiaoqing, Zhang Yinghe. Citrus Bacterial Canker Disease: Pathogen Identification and Bactericides Screening[J]. Chinese Agricultural Science Bulletin, 2021, 37(24): 146-153.

图/表 12

参考文献 32

[33]	Heydarpanah S, Rezaei R, Taghavi S M, et al. Efficacy of different copper compounds in the control of Xanthomonas citri subsp. citri pathotypes A and A*[J]. Journal of Phytopathology, 2020, 168:73-80. doi: 10.1111/jph.12869
[34]	Behkau F, Belasque J R J, Graham J H, et al. Effect of frequency of copper applications on control of citrus canker and the yield of young bearing sweet orange trees[J]. Crop Protection, 2010, 29(3):300-305. doi: 10.1016/j.cropro.2009.12.010 URL
[35]	陈仁强, 林培, 林树政. 海南琼中绿橙溃疡病田间药剂防治试验初报[J]. 农业科技通讯, 2018(07):140-141.
[36]	李建挥, 张浩琪, 李娜, 等. 5种表面活性剂对铜制剂防治冰糖橙溃疡病效果的影响[J]. 湖南农业科学, 2013(5):71-73.
[1]	姚廷山, 周彦, 周常勇. 柑橘溃疡病菌分化及防治研究进展[J]. 园艺学报, 2015, 42(9):1699-1706.
[2]	Lan B T N, Christian V, Philippe J, et al. From local surveys to global surveillance: three high-throughput genotyping methods for epidemiological monitoring of Xanthomonas citri pv. citri Pathotypes[J]. Applied and Environmental Microbiology, 2009, 75(4):1173-1184. doi: 10.1128/AEM.02245-08 URL
[3]	陈娇梅, 蔡学清, 邱思鑫, 等. 柑橘溃疡病生防细菌的分离鉴定[J]. 热带作物学报, 2014, 35(7):1398-1403.
[4]	Ali M R, Hasan M F, Lia R S, et al. Isolation and characterization of a canker disease causing pathogen from Citrus aurantifolia and evaluation of its biological control measure[J]. Journal of Entomology and Zoology Studies, 2017, 5:1526-1532.
[5]	尤华峰, 刘霁雯, 李雪培, 等. 杀菌剂对柑橘溃疡病菌室内毒力测定方法的建立及应用[J]. 湖北植保, 2019, 172(1):30-34.
[6]	Daungfu O, Youpensuk S, Lumyong S. Endophytic bacteria isolated from citrus plants for biological control of citrus canker in Lime plants[J]. Tropical life sciences research, 2019, 30(1):73. doi: 10.21315/tlsr2019.30.1.5 pmid: 30847034
[7]	王玉根, 陈道茂, 林荷芳, 等. 20%噻菌铜胶悬剂防治柑橘溃疡病药效试验[J]. 广西园艺, 2002(4):24-25.
[8]	李建挥, 张浩琪, 李娜, 等. 5种表面活性剂对铜制剂防治冰糖橙溃疡病效果的影响[J]. 湖南农业科学, 2013(5):71-73.
[9]	Behlau F, Canteros B L, Minsavage G V, et al. Molecular characterization of copper resistance genes from Xanthomonas citri subsp. citri and Xanthomonas alfalfa subsp. citrumelonis[J]. Applied and Environmental Microbiology, 2011, 77:4089-4096. doi: 10.1128/AEM.03043-10 URL
[10]	Michavila G, Adler C, De Gregorio P R, et al. Pseudomonas protegens CS 1 from the lemon phyllosphere as a candidate for citrus canker biocontrol agent[J]. Plant Biology, 2017, 19(4):608-617. doi: 10.1111/plb.12556 pmid: 28194866
[11]	方中达. 植病研究方法(第3版)[M]. 北京: 中国农业出版社, 1998:197-200.
[12]	胡春华, 邓子牛. 柑橘溃疡病致病基因pthA的克隆及序列分析[J]. 湖南农业大学学报:自然科学版, 2008, 34(2):173-176.
[13]	王中康, 孙宪昀, 夏玉先, 等. 柑桔溃疡病菌PCR快速检验检疫技术研究[J]. 植物病理学报, 2004, 34(1):14-20.
[14]	陈先锋, 张慧丽, 赵雷. 台湾柠檬上柑橘溃疡病菌的分离鉴定[J]. 浙江农业学报, 2017, 29(1):101-105.
[15]	Coletta-Filho H D, Takita M A, Souza A A, et al. Primers based on the rpf gene region provide improved detection of Xanthomonas axonopodis pv. citri in naturally and artificially infected citrus plants[J]. Journal of applied microbiology, 2006, 100(2):279-285. pmid: 16430504
[16]	高爽, 陈武, 戴良英. 湖南省柑橘溃疡病菌gyrB和16S rRNA的扩增和序列分析[J]. 江苏农业科学, 2016, 44(5):76-78.
[17]	李云锋, 李祥. 柑桔溃疡病菌离体叶接种检验法的研究[J]. 华中农业大学学报, 2000, 19(5):421-423.
[18]	东秀珠, 蔡妙英. 常见细菌系统鉴定手册[M]. 北京: 科学出版社, 2001:370-377.
[19]	郭静, 宋雪, 邹丽芳, 等. 柑橘溃疡病菌外膜蛋白XAC1347在耐受铜杀菌剂中的功能[J]. 植物病理学报, 2015, 45(5):455-60.
[20]	孙广宇, 宗兆峰. 植物病理学实验指导[M]. 北京: 中国农业出版社. 2002:139-140.
[21]	王辉, 冯卫华, 曾晓房, 等. 柠檬皮中柠檬苦素抑制霉菌的活性及稳定性[J]. 食品科技, 2019, 44(3):216-220.
[22]	吴明琼. 柑橘溃疡病菌拮抗细菌筛选和药剂防治试验[D]. 南宁:广西大学, 2018:38-48.
[23]	Caicedo J C, Villamizar S, Ferro M, et al. Bacteria from the citrus phylloplane can disrupt cell-cell signalling in Xanthomonas citri and reduce citrus canker disease severity[J]. Plant Pathology, 2016, 65(5):782-791. doi: 10.1111/ppa.2016.65.issue-5 URL
[24]	李新宇, 李磊, 石延霞, 等. 黄瓜棒孢叶斑病拮抗细菌的筛选、鉴定及防治效果[J]. 植物保护学报, 2020, 47(3):620-627.
[25]	尹敬芳, 张文华, 李健强, 等. 辣椒疫病生防菌的筛选及其抑菌机制初探[J]. 植物病理学报, 2007, 37(1):88-94.
[26]	张妙宜, 陈志杰, 陈宇丰, 等. 1株拮抗细菌的分离鉴定及其对香蕉枯萎病等病原菌的抑制活性测定[J]. 热带作物学报, 2017, 38(11):2151-2159.
[27]	Stein T. Bacillus subtilis antibiotics: structures, syntheses and specific functions[J]. Molecular microbiology, 2005, 56(4):845-57. doi: 10.1111/j.1365-2958.2005.04587.x URL
[28]	任建国, 黄思良, 岑贞陆, 等. 21种药剂对柑桔溃疡病的防治试验[J]. 中国南方果树, 2005, 34(3):13-15.
[29]	钟德志, 刘守洪. 4种农药对柑橘溃疡病的防治效果[J]. 浙江柑橘, 2014, 31(2):23-24.
[30]	吴晓金, 易图永, 邓子牛, 等. 杀菌剂对柑橘溃疡病菌的毒力测定[J]. 农学学报, 2011(7):13-16.
[31]	Graham J H, Dewdney M M, Yonce A D. Comparison of copper formulations for control of citrus canker on 'Hamlin' orange[J]. Proceedings of the Florida State Horticultural Society, 2011, 124:79-84.
[32]	Guerra G S, Balan A. Genetic and structural determinants on iron assimilation pathways in the plant pathogen Xanthomonas citri subsp. citri and Xanthomonas sp.[J]. Brazilian Journal of Microbiology, 2020, 51:1219-1231. doi: 10.1007/s42770-019-00207-x URL

引物名称	引物序列(5’-3’)
P8	GTTGCCCAGTTATCTCGCCCTGATC
P9	CCAATCCCTGCCGACGCTCAGGTAGT
JYF5	TTCGGCGTCAACAACCTG
JFR5	AACTCCAGCACATACGGGTC
Xac01	CGCCATCCCCACCACCACCACGAC
Xac02	AACCGCTCAATGCCATCCACTTCA
GGS1F	CCCTGCTGCTGACCTTCTTCT
GGS2R	GGTTGACCGTGGTTTCCCATA
27F	AGAGTTTGATCCTGGCTCAG
1492R	TACGGCTACCTTGTTACGACTT

引物名称	引物序列(5’-3’)
P8	GTTGCCCAGTTATCTCGCCCTGATC
P9	CCAATCCCTGCCGACGCTCAGGTAGT
JYF5	TTCGGCGTCAACAACCTG
JFR5	AACTCCAGCACATACGGGTC
Xac01	CGCCATCCCCACCACCACCACGAC
Xac02	AACCGCTCAATGCCATCCACTTCA
GGS1F	CCCTGCTGCTGACCTTCTTCT
GGS2R	GGTTGACCGTGGTTTCCCATA
27F	AGAGTTTGATCCTGGCTCAG
1492R	TACGGCTACCTTGTTACGACTT

名称	产酸	产气
D-果糖	+	—
D-甘露糖	—	—
D-半乳糖	—	—
蔗糖	—	—
蜜二糖	+	—
海藻糖	—	—
D-甘露醇	—	—
丙三醇	—	—
肌醇	—	—
核糖醇	—	—
山梨醇	—	—

名称	产酸	产气
D-果糖	+	—
D-甘露糖	—	—
D-半乳糖	—	—
蔗糖	—	—
蜜二糖	+	—
海藻糖	—	—
D-甘露醇	—	—
丙三醇	—	—
肌醇	—	—
核糖醇	—	—
山梨醇	—	—

试验	结果
淀粉水解	+
过氧化氢酶	+
明胶液化	+
硝酸盐还原	+
产氨	+
吲哚	—
V-P	—
甲基红	—
氧化酶	—
