Optimization of Culture Medium and Fermentation Parameters of Bacillus cereus MA23 Antagonistic to Kiwifruit Canker

doi:10.11924/j.issn.1000-6850.casb2020-0108

Abstract

Abstract:

As an important biocontrol bacterium, Bacillus cereus MA23 exhibits good antagonistic effect on the pathogen of kiwifruit canker, Pseudomonas syringae pv. actinidiae. To promote its application in the control of the diseases, it is necessary to improve the biomass and antimicrobial activity of strain MA23. Thus, orthogonal test and single factor experiment were selected for the optimization of culture medium and fermentation parameters. Through variance analysis of orthogonal experiment results, it was demonstrated that peptone, soluble starch, K₂HPO₄ and MgSO₄ were highly significant factors, and NaNO₃ was a significant factor while glucose was not a significant factor. These factors affected the test result in an order of soluble starch> K₂HPO₄> peptone> MgSO₄> NaNO₃> glucose, and A₁B₄C₄D₁E₂F₂was determined as the optimal combination. So the optimal culture medium for MA23 was 0.8% glucose, 0.2% peptone, 3.5% soluble starch, 0.05% NaNO₃, 0.2% K₂HPO₄, 0.2% MgSO₄, 0.12% CaCO₃, 0.035% MnSO₄. After optimization of the medium, the biomass and antimicrobial activity of strain MA23 fermentation broth increased by 41% and 37.2%, respectively. After the single factor experiments, the optimal fermentation condition was determined as fellows: the initial pH of the medium was 6.5, the fermentation temperature was 30℃, the inoculation size was 8%, the liquid medium volume was 70 mL, and the rotation speed was 180 r/min. After optimization of fermentation conditions, the biomass and antimicrobial activity of strain MA23 fermentation broth increased by 28.2% and 25.6%, respectively. In conclusion, the biomass and antimicrobial activity of Bacillus cereus MA23 are improved significantly through optimization of culture medium and fermentation parameters, and this will lay the foundation for the further application of strain MA23.

Key words: Bacillus cereus MA23, orthogonal test, optimization of fermentation medium, optimization of fermentation parameters, viable count, antagonistic activity

CLC Number:

Q939.96

Zhu Haiyun, Ma Yu, Ke Yang, Li Bo. Optimization of Culture Medium and Fermentation Parameters of Bacillus cereus MA23 Antagonistic to Kiwifruit Canker[J]. Chinese Agricultural Science Bulletin, 2021, 37(7): 112-118.

Figures/Tables 9

References 32

[1]	Haverkort A J, Boonekamp P M, Hutten R, et al. Societal costs of late blight in potato and prospects of durable resistance through cisgenic modification[J]. Potato Research, 2008,51(1):47-57.
[2]	Velivelli S L S, De Vos P, Kromann P, et al. Biological control agents: from field to market, problems, and challenges[J]. Trends in Biotechnology, 2014,32(10):493-496.
[3]	Naclerio G, Ricca E, Sacco M, et al. Antimicrobial activity of a newly identified bacteriocin of Bacillus cereus[J]. Applied and Environmental Microbiology, 1993,59(12):4313-4316. URL pmid: 8285719
[4]	Ghanbari M, Rezaei M, Soltani M, et al. Production of bacteriocin by a novel Bacillus sp. Strain RF 140, an intestinal bacterium of Caspian Frisian Roach (Rutilus frisii Kutum)[J]. Iranian Journal of Veterinary Research, 2009,10:267-272.
[5]	Riley M A, Wertz J E. Bacteriocins: evolution, ecology, and application[J]. Annual Review of Microbiology, 2002,56(1):117-137.
[6]	Yeaman M R, Yount N Y. Mechanisms of antimicrobial peptide action and resistance[J]. Pharmacological Reviews, 2003,55(1):27-55. URL pmid: 12615953
[7]	Mandal H, Chakraborty P, Das S, et al. Biocontrol of virulent Ralstonia solanacearum isolates by an indigenous Bacillus cereus[J]. Journal of Agricultural Technology, 2017,13(1):19-30.
[8]	车建美, 刘波, 张彦, 等. 青枯病生防菌蜡状芽孢杆菌(ANTI-8098A)的绿色荧光蛋白基因(gfp)转导及其生物学特性的变化[J]. 农业生物技术学报, 2010,18(2):337-345.
[9]	Douriet-Gámez N R, Maldonado-Mendoza I E, Ibarra-Laclette E, et al. Genomic analysis of Bacillus sp. Strain B25, a biocontrol agent of maize pathogen Fusarium verticillioides[J]. Current Microbiology, 2018,75(3):247-255. URL pmid: 29051980
[10]	黄秋斌, 张颖, 刘凤英, 等. 蜡样芽孢杆菌B3-7在大田小麦根部的定殖动态及其对小麦纹枯病的防治效果[J]. 生态学报, 2014,34(10):2559-2566.
[11]	柯杨, 李勃, 齐凡. 芽孢杆菌在植物真菌病害防治中的应用[J]. 保鲜与加工, 2012,12(5):39-43.
[12]	Banerjee G, Gorthi S, Chattopadhyay P. Beneficial effects of bio-controlling agent Bacillus cereus IB311 on the agricultural crop production and its biomass optimization through response surface methodology[J]. Anais da Academia Brasileira de Ciencias, 2017,90(S1):2149-2159.
[13]	Sadiq H, Jamil N. Antagonistic behaviour of organic compounds from Bacillus species and Brevundimonas specie[J]. Pakistan Journal of Pharmaceutical Sciences, 2018,31(3):919-926. URL pmid: 29716874
[14]	韩长志. 植物病害生防菌的研究现状及发展趋势[J]. 中国森林病虫, 2015,34(1):33-37,25.
[15]	贺字典, 高玉峰. 生防菌在植物病害防治中的研究进展[J]. 河北职业技术师范学院学报, 2003,17(2):56-59.
[16]	Chattopadhyay P, Banerjee G, Mukherjees S. Recent trends of modern bacterial insecticides for pest control practice in integrated crop management system[J]. Biotech, 2017,7(1):60.
[17]	Sarrau B D, Clavel T, Clerté C, et al. Influence of anaerobiosis and low temperature on Bacillus cereus growth, metabolism, and membrane properties[J]. Applied & Environmental Microbiology, 2012,78(6):1715-1723.
[18]	Arul Jose P, Sivakala K K, Jebakumar S R D. Formulation and statistical optimization of culture medium for improved production of antimicrobial compound by Streptomyces sp. JAJ06[J]. International Journal of Microbiology, 2013: 1-9.
[19]	Singh P, Shera S S, Banik J, et al. Optimization of cultural conditions using response surface methodology versus artificial neural network and modeling of L-glutaminase production by Bacillus cereus MTCC 1305[J]. Bioresource Technology, 2013,137:261-269. URL pmid: 23587828
[20]	Ferrante P, Takikawa Y, Scortichini M. Pseudomonas syringae pv. actinidiae strains isolated from past and current epidemics to Actinidia spp. reveal a diverse population structure of the pathogen[J]. European Journal of Plant Pathology, 2015,142(4):677-689.
[21]	Everett K R, Taylor R K, Romberg M K, et al., First report of Pseudomonas syringae pv. actinidiae causing kiwifruit bacterial canker in New Zealand[J]. Australasian Plant Disease Notes, 2011,6:67-71.
[22]	Masami N, Masao G, Katsumi A, et al. Nucleotide sequence and organization of copper resistance genes Frompseudomonas syringae pv. actinidiae[J]. European Journal of Plant Pathology, 2004,110(2):223-226.
[23]	Han H S, Koh Y J, Hur J S, et al. Occurrence of the strastrb streptomycin resistance genes in Pseudomonas species isolated from kiwifruit plants[J]. The Journal of Microbiology, 2004,42(4):365-368. URL pmid: 15650697
[24]	朱海云, 李勃, 李燕, 等, 丁香假单胞菌猕猴桃致病变种的遗传多样性及进化关系[J]. 微生物学杂志, 2013,33(4):72-77.
[25]	刘宁. 番茄灰霉病菌生防细菌BAB-1的鉴定及发酵工艺的优化[D]. 保定:河北农业大学, 2009:5-14.
[26]	陈燕飞. 两种细菌学检查方法的比较[J]. 中国农学通报, 2010,26(17):139-141.
[27]	柯杨, 马瑜, 李勃, 等. 生防枯草芽孢杆菌A97与化学杀菌剂的相容性研究[J]. 陕西农业科学, 2013(6):44-47.
[28]	邓振伟, 于萍, 陈玲. SPSS软件在正交试验设计、结果分析中的应用[J]. 电脑学习, 2009(5):15-17.
[29]	李晔, 张西轩, 曹广秀, 等. 产胶原酶的蜡样芽胞杆菌发酵条件优化及酶的分离纯化[J]. 微生物学通报, 2016,43(7):1419-1428.
[30]	Nasser E B. Antimicrobial substances producing by air flora[J]. Arab Gulf Jourmal of Scientific Research, 2003,21:134-139.
[31]	Nasser E B, Samar S Q. Antimicrobial activity of Bacillus cereus: isolation, identification and the effect of carbon and nitrogen source on its antagonistic activity[J]. Journal of Microbiology and Antimicrobials, 2016,8(2):7-13.
[32]	肖怀秋, 李玉珍. 微生物培养基优化方法研究进展[J]. 酿酒科技, 2010(1):90-94.

编号	因素/%						活菌数/(×10⁸ CFU/mL)
编号	A	B	C	D	E	F	Ⅰ	Ⅱ	Ⅲ
1	3(2.4)	3(0.15)	3(2.5)	1(0.05)	1(0.1)	2(0.2)	5.7	5.5	6.7
2	3	2(0.1)	1(0.5)	4(0.2)	2(0.2)	1(0.1)	3	4.5	4.2
3	1(0.8)	1(0.05)	1	1	1	1	5.1	5.8	6.9
4	2(1.6)	3	4(3.5)	4	1	1	7.9	9	11.6
5	1	3	2(1.5)	3(0.15)	2	1	9	5	8.7
6	4(3.2)	4(0.2)	4	1	2	1	13.4	15.3	15.2
7	4	2	3	3	1	1	7.0	5.9	5.4
8	1	2	4	2(0.1)	1	2	8.3	9.5	10.1
9	3	1	4	3	2	2	13	13.7	12.9
10	3	4	2	2	1	1	7.8	9.1	7.5
11	4	1	2	4	1	2	10.1	7.5	7.2
12	2	1	3	2	2	1	6.1	6.6	6.6
13	2	4	1	3	1	2	6.8	6.6	7.2
14	1	4	3	4	2	2	9.5	8.6	10.3
15	4	3	1	2	2	2	7.9	5.9	7.0
16	2	2	2	1	2	2	11	8.7	9.8
K₁_j	96.8	101.5	70.9	109.1	180.2	186.6
K₂_j	97.9	87.4	101.4	92.4	215.9	209.5
K₃_j	93.6	89.9	83.9	101.2
K₄_j	107.8	117.3	139.9	93.4

编号	因素/%						活菌数/(×10⁸ CFU/mL)
编号	A	B	C	D	E	F	Ⅰ	Ⅱ	Ⅲ
1	3(2.4)	3(0.15)	3(2.5)	1(0.05)	1(0.1)	2(0.2)	5.7	5.5	6.7
2	3	2(0.1)	1(0.5)	4(0.2)	2(0.2)	1(0.1)	3	4.5	4.2
3	1(0.8)	1(0.05)	1	1	1	1	5.1	5.8	6.9
4	2(1.6)	3	4(3.5)	4	1	1	7.9	9	11.6
5	1	3	2(1.5)	3(0.15)	2	1	9	5	8.7
6	4(3.2)	4(0.2)	4	1	2	1	13.4	15.3	15.2
7	4	2	3	3	1	1	7.0	5.9	5.4
8	1	2	4	2(0.1)	1	2	8.3	9.5	10.1
9	3	1	4	3	2	2	13	13.7	12.9
10	3	4	2	2	1	1	7.8	9.1	7.5
11	4	1	2	4	1	2	10.1	7.5	7.2
12	2	1	3	2	2	1	6.1	6.6	6.6
13	2	4	1	3	1	2	6.8	6.6	7.2
14	1	4	3	4	2	2	9.5	8.6	10.3
15	4	3	1	2	2	2	7.9	5.9	7.0
16	2	2	2	1	2	2	11	8.7	9.8
K₁_j	96.8	101.5	70.9	109.1	180.2	186.6
K₂_j	97.9	87.4	101.4	92.4	215.9	209.5
K₃_j	93.6	89.9	83.9	101.2
K₄_j	107.8	117.3	139.9	93.4

方差来源	Ⅲ型平方和	自由度	均方	F	P
矫正模型	3.332E+18^*	14	2.380E+17	16.826	0.000
截距	3.269E+19	1	3.269E+19	2310.567	0.000
A	9.387E+16	3	3.129E+16	2.212	0.105
B	4.654E+17	3	1.551E+17	10.967	0.000
C	2.247E+18	3	7.489E+17	52.942	0.000
D	1.515E+17	3	5.049E+16	3.569	0.024
E	2.655E+17	1	2.655E+17	18.769	0.000
F	1.093E+17	1	1.093E+17	7.723	0.009
误差	4.668E+17	33	1.415E+16
总计	3.649E+19	48
校正的总计	3.799E+18	47

方差来源	Ⅲ型平方和	自由度	均方	F	P
矫正模型	3.332E+18^*	14	2.380E+17	16.826	0.000
截距	3.269E+19	1	3.269E+19	2310.567	0.000
A	9.387E+16	3	3.129E+16	2.212	0.105
B	4.654E+17	3	1.551E+17	10.967	0.000
C	2.247E+18	3	7.489E+17	52.942	0.000
D	1.515E+17	3	5.049E+16	3.569	0.024
E	2.655E+17	1	2.655E+17	18.769	0.000
F	1.093E+17	1	1.093E+17	7.723	0.009
误差	4.668E+17	33	1.415E+16
总计	3.649E+19	48
校正的总计	3.799E+18	47

优化阶段	活菌数		抑菌圈半径
优化阶段	数据/(CFU/mL)	优化效率/%	数据/cm	优化效率/%
A	13.9±0.89	/	9.84±0.87	/
B	19.6±1.20	41.0^*	13.50±0.76	37.2^*
C	25.12±0.60	28.2^**	16.96±1.24	25.6^**
