Identification, Evolution and Functional Analysis of ApDUF247 Gene Family in Andrographis paniculata

doi:10.11924/j.issn.1000-6850.casb2025-0369

Abstract

Abstract:

The DUF247 gene family plays a significant role in plant growth, development, and stress responses. The purpose of this study aims to reveal the biological functions of the ApDUF247 gene family in Andrographis paniculata and its reaction mechanisms under adverse conditions. The members of the ApDUF247 gene family were identified by bioinformatics method, and their physical and chemical properties, chromosome location, evolutionary relationships, gene structure, cis-regulatory element distribution, expression patterns in different tissues and stress treatments, protein interaction and the expression correlation between ApDUF247 and andrographolide biosynthesis were analyzed. There are twelve ApDUF247 in Andrographis paniculata, which are unevenly distributed on 8 chromosomes, and their structures and functions are diverse. Andrographis paniculata has 11, 7 and 1 pairs of collinear DUF247s genes respectively with Strobilanthes cusia, Sesamum indicum and Arabidopsis thaliana. The promoter region of ApDUF247s is rich in hormone response, photoreaction and transcription factor binding elements. ApDUF247s has tissue-specific expression, which shows different expression patterns under different stress treatments. ApDUF247_8 interacts with 5 serine/threonine protein kinases, ApDUF247_3 interacts with 5 peroxisome-related proteins and 1 E3 ubiquitin lipase, and ApDUF247_6, ApDUF247_9 and ApDUF247_12 are highly correlated with the gene of the ligustrazine biosynthesis pathway (Cor>0.8), and are predicted to be candidate regulatory genes for ligustrazine biosynthesis. This study lays an analytical foundation for preliminarily understanding the biological functions of DUF247 genes in Andrographis paniculata under non-biological stress and their involvement in the regulatory mechanism of andrographolide biosynthesis.

Key words: Andrographis paniculata, DUF247, gene expression, genetics evolution, biological function, abiotic stress, andrographolide, regulatory mechanism, bioinformatics

ZHANG Long, XU Shiqiang, LI Jingyu, LI Xulong, WANG Jihua. Identification, Evolution and Functional Analysis of ApDUF247 Gene Family in Andrographis paniculata[J]. Chinese Agricultural Science Bulletin, 2026, 42(3): 99-108.

Figures/Tables 8

References 27

[1]	MISTRY J, CHUGURANSKY S, WILLIAMS L, et al. Pfam: The protein families database in 2021[J]. Nucleic acids research, 2021, 49(D1):D412-D419.
[2]	YANG S, LI W, MIAO H, et al. REL2, A gene encoding an unknown function protein which contains DUF630 and DUF632 domains controls leaf rolling in rice[J]. Rice, 2016, 9(1):37. doi: 10.1186/s12284-016-0105-6 URL
[3]	LU X, LI Y, AKHTAR M, et al. A DUF966 gene family member OsDSR3 positively regulates alkali stress tolerance in rice[J]. Plant science, 2024, 343:112072. doi: 10.1016/j.plantsci.2024.112072 URL
[4]	CUI Y, WANG M, ZHOU H, et al. OsSGL, a novel DUF1645 domain-containing protein, confers enhanced drought tolerance in transgenic rice and Arabidopsis[J]. Frontiers in plant science, 2016, 7:2001.
[5]	NABI R B, TAYADE R, HUSSAIN A, et al. A novel DUF569 gene is a positive regulator of the drought stress response in Arabidopsis[J]. International journal of molecular sciences, 2021, 22(10):5316. doi: 10.3390/ijms22105316 URL
[6]	LI Y, WANG W, ZHANG N, et al. Antagonistic regulation of ABA responses by duplicated tandemly repeated DUF538 protein genes in Arabidopsis[J]. Plants, 2023, 12(16):2989. doi: 10.3390/plants12162989 URL
[7]	李云宾, 黎玉萍, 成钦, 等. 芦笋DUF247基因家族成员鉴定及表达分析[J]. 生物技术通报, 2025, 41(1):198-209. doi: 10.13560/j.cnki.biotech.bull.1985.2024-0596
[8]	ZHANG F, LIU Y, LIU F, et al. Genome-wide characterization and analysis of rice DUF247 gene family[J]. BMC Genomics, 2024, 25(1):613. doi: 10.1186/s12864-024-10515-8
[9]	ISHKA M R, SUSSMAN H, HU Y, et al. Natural variation in salt-induced changes in root:shoot ratio reveals SR3G as a negative regulator of root suberization and salt resilience in Arabidopsis[J]. Biorxiv, 2024, 4(9):588564.
[10]	WANNITIKUL P, WATTANA-AMORN P, SATHITNAITHAM S, et al. Disruption of a DUF247 containing protein alters cell wall polysaccharides and reduces growth in Arabidopsis[J]. Plants, 2023, 12(10):1977.
[11]	SELVAM K, SUDHAKAR C, RAGU PRASATH A, et al. Anti-dengue viral protein NS5 and antibacterial efficacy of andrographolide from Andrographis paniculata: an in silico approach[J]. Applied biochemistry and biotechnology, 2025, 197:4157-4175. doi: 10.1007/s12010-025-05191-7
[12]	LI Z, YAO L, LIU Z, et al. Andrographolide sulfonates and xiyanping: a review of chemical composition, pharmacological activities, clinical applications, and adverse reactions[J]. Pharmaceuticals, 2025, 18(2):183. doi: 10.3390/ph18020183 URL
[13]	CHUNGLOO D, TISARUM R, SAMPHUMPHUANG T, et al. Mitigation of water-deficit stress, physio-morphological adaptation, and elevation of andrographolide in Andrographis paniculata using foliar glycine betaine[J]. Journal of plant growth regulation, 2023, 42(10):6273-6285. doi: 10.1007/s00344-022-10818-8
[14]	李静宇, 孙铭阳, 徐世强, 等. 穿心莲R2R3-MYB基因家族的鉴定与表达分析[J]. 中国中药杂志, 2022, 47(1):72-84.
[15]	张龙, 徐世强, 李静宇, 等. 穿心莲TCP基因家族全基因组鉴定及非生物胁迫下的表达分析[J]. 中国中药杂志, 2024, 49(2):379-388.
[16]	CHEN C, WU Y, LI J, et al. TBtools-II: a “one for all, all for one” bioinformatics platform for biological big-data mining[J]. Molecular plant, 2023, 16(11):1733-1742. doi: 10.1016/j.molp.2023.09.010 URL
[17]	SUN W, LENG L, YIN Q, et al. The genome of the medicinal plant Andrographis paniculata provides insight into the biosynthesis of the bioactive diterpenoid neoandrographolide[J]. The plant journal, 2019, 97(5):841-857. doi: 10.1111/tpj.2019.97.issue-5 URL
[18]	LUO C, AKHTAR M, MIN W, et al. Domain of unknown function (DUF) proteins in plants: function and perspective[J]. Protoplasma, 2024, 261(3):397-410. doi: 10.1007/s00709-023-01917-8
[19]	MANZANARES C, BARTH S, THOROGOOD D, et al. A gene encoding a DUF247 domain protein cosegregates with the S self-incompatibility locus in perennial ryegrass[J]. Molecular biology and evolution, 2016, 33(4):870-884. doi: 10.1093/molbev/msv335 pmid: 26659250
[20]	ZHAO M, ZHANG B, MA J, et al. Genome-wide estimation of evolutionary distance and phylogenetic analysis of homologous genes[J]. Bio-protocol, 2018, 8(23):e3097. doi: 10.21769/BioProtoc.3097 pmid: 34532544
[21]	LI T, ZHENG J, NOUSIAS O, et al. The american cherimoya genome reveals insights into the intra-specific divergence, the evolution of magnoliales, and a putative gene cluster for acetogenin biosynthesis[J]. Plants, 2024, 13(5):636. doi: 10.3390/plants13050636 URL
[22]	FU J, WANG L, PEI W, et al. ZmEREB92 interacts with ZmMYC2 to activate maize terpenoid phytoalexin biosynthesis upon Fusarium graminearum infection through jasmonic acid/ethylene signaling[J]. New phytologist, 2023, 237(4):1302-1319. doi: 10.1111/nph.v237.4 URL
[23]	YANG H, ZHANG Y, LIU Y, et al. A novel ABA-induced transcript factor from Millettia pinnata, MpAITR1, enhances salt and drought tolerance through ABA signaling in transgenic Arabidopsis[J]. Journal of plant physiology, 2023, 288:154060. doi: 10.1016/j.jplph.2023.154060 URL
[24]	MA R, LIU B, GENG X, et al. Biological function and stress response mechanism of MYB transcription factor family genes[J]. Journal of plant growth regulation, 2023, 42(1):83-95. doi: 10.1007/s00344-021-10557-2
[25]	SWINNEN G, De MEYER M, POLLIER J, et al. The basic helix-loop-helix transcription factors MYC1 and MYC2 have a dual role in the regulation of constitutive and stress-inducible specialized metabolism in tomato[J]. New phytologist, 2022, 236(3):911-928. doi: 10.1111/nph.v236.3 URL
[26]	RAMACHANDIRAN I, VIJAYAKUMAR A, RAMYA V, et al. Arabidopsis serine/threonine/tyrosine protein kinase phosphorylates oil body proteins that regulate oil content in the seeds[J]. Scientific reports, 2018, 8(1):1154. doi: 10.1038/s41598-018-19311-3
[27]	LANDOWSKI M, BHUTE V J, GRINDEL S, et al. Transmembrane protein 135 regulates lipid homeostasis through its role in peroxisomal DHA metabolism[J]. Communications biology, 2023, 6(1):8. doi: 10.1038/s42003-022-04404-7 pmid: 36599953

基因ID	基因名	氨基酸长度	分子量	等电点	不稳定系数	总平均亲水性	亚细胞定位
CXN00002081-RA	ApDUF247_1	473	52700.14	8.51	48.23	-0.669	细胞质
CXN00004073-RA	ApDUF247_2	529	58971.57	5.84	47.51	-0.198	细胞质
CXN00003503-RA	ApDUF247_3	1680	186638.71	5.34	49.32	-0.115	叶绿体
CXN00012583-RA	ApDUF247_4	859	98005.69	6.31	42.15	-0.352	过氧化物酶体
CXN00000514-RA	ApDUF247_5	545	61351.73	6.01	43.98	-0.128	内质网
CXN00000675-RA	ApDUF247_6	366	41693.45	5.91	47.45	-0.297	细胞质
CXN00024588-RA	ApDUF247_7	518	59123.47	5.96	49.4	-0.309	细胞质
CXN00024587-RA	ApDUF247_8	503	57823.47	6.82	39.33	-0.298	细胞质
CXN00016149-RA	ApDUF247_9	127	14731.38	6.83	34.73	-0.276	细胞质
CXN00021843-RA	ApDUF247_10	160	18016.36	5.49	58.26	-0.642	叶绿体
CXN00014251-RA	ApDUF247_11	219	24515.95	6.38	52.31	-0.288	线粒体
CXN00018330-RA	ApDUF247_12	419	47110	7.6	41.1	-0.024	细胞质

基因ID	基因名	氨基酸长度	分子量	等电点	不稳定系数	总平均亲水性	亚细胞定位
CXN00002081-RA	ApDUF247_1	473	52700.14	8.51	48.23	-0.669	细胞质
CXN00004073-RA	ApDUF247_2	529	58971.57	5.84	47.51	-0.198	细胞质
CXN00003503-RA	ApDUF247_3	1680	186638.71	5.34	49.32	-0.115	叶绿体
CXN00012583-RA	ApDUF247_4	859	98005.69	6.31	42.15	-0.352	过氧化物酶体
CXN00000514-RA	ApDUF247_5	545	61351.73	6.01	43.98	-0.128	内质网
CXN00000675-RA	ApDUF247_6	366	41693.45	5.91	47.45	-0.297	细胞质
CXN00024588-RA	ApDUF247_7	518	59123.47	5.96	49.4	-0.309	细胞质
CXN00024587-RA	ApDUF247_8	503	57823.47	6.82	39.33	-0.298	细胞质
CXN00016149-RA	ApDUF247_9	127	14731.38	6.83	34.73	-0.276	细胞质
CXN00021843-RA	ApDUF247_10	160	18016.36	5.49	58.26	-0.642	叶绿体
CXN00014251-RA	ApDUF247_11	219	24515.95	6.38	52.31	-0.288	线粒体
CXN00018330-RA	ApDUF247_12	419	47110	7.6	41.1	-0.024	细胞质
