Multi-component Content Analysis and Water Quality Evaluation of Groundwater in Anxin

doi:10.11924/j.issn.1000-6850.casb2021-0134

Abstract

Abstract:

To find out the chemical characteristics of groundwater and the present situation of water quality in Anxin, 45 groups of groundwater samples were selected and determined by the method of instrument analysis and volumetric method. The main ionic characteristics of groundwater in Anxin were analyzed by using comprehensive descriptive mathematical statistics and ternary phase diagrams. Groundwater quality was evaluated by comprehensive evaluation method. The results show that: (1) in this area the groundwater is slightly alkaline, hydro-chemical type is mainly HCO₃-Na; (2) pH and metasilicate acid have the lowest spatial variation (CV<30%); the spatial variability of potassium and nitrate are the highest (CV>100%); the spatial variation of other indexes are moderate (CV: 30%-100%); (3) the main indexes that affecting the quality of groundwater environment are TDS, SO₄^2-, F^- and total hardness; (4) the results of water quality evaluation show that the groundwater quality is well, mostly are III water. The results are important for understanding the present situation of groundwater quality in Anxin.

Key words: instrumental analysis, volumetric analysis, coefficient of variation, groundwater, hydro-chemical characteristics, water quality assessment

CLC Number:

P641.3

Jia Liangliang, Tian Xiaohua, Liu Huajie. Multi-component Content Analysis and Water Quality Evaluation of Groundwater in Anxin[J]. Chinese Agricultural Science Bulletin, 2021, 37(14): 78-83.

Figures/Tables 7

References 16

[1]	周长松, 郑秀清, 臧红飞, 等. 地下水环境容量综合指标体系的构建及其应用[J]. 中国农学通报, 2012,28(29):259-265.
[2]	刘启龙, 车丽娜. 绥化市水源地地下水污染特征分析及水质评价[J]. 环境科学学报, 2019,39(10):3528-3534.
[3]	孙宏勇, 刘小京, 邵立威, 等. 不同种植模式对河北低平原区域地下水平衡和水分经济利用效率等的影响[J]. 中国农学通报, 2014,30(32):214-220.
[4]	陈望河. 河北地下水[M]. 北京: 地震出版社, 1999: 172-178.
[5]	张兆吉, 费宇红, 郭春艳, 等. 华北平原区域地下水污染评价[J]. 吉林大学学报:地球科学版, 2012,42(5):1456-1461.
[6]	温海威, 吕聪, 王天野, 等. 沈阳地区农村地下饮用水中重金属健康风险评价[J]. 中国农学通报, 2012,28(23):242-247.
[7]	屈吉鸿, 李潇, 张艺锋, 等. 新乡市化工集聚区地下水化学特征及成因分析[J]. 科学技术与工程, 2019,19(34):95-102.
[8]	中国国家标准化管理委员会, GB/T 14848—2017,地下水环境质量标准[S].北京:中国标准出版社, 2017.
[9]	余淼, 李瑜. 天津市农区地下水硝酸盐污染现状调查与评价[J]. 中国农学通报, 2014,30(20):219-222.
[10]	郜毓, 崔国屹, 王康振, 等. 沋河流域下游水化学特征及影响因素分析[J]. 中国农学通报2019, 35(31):107-114.
[11]	吴庭雯, 袁磊, 韩双宝, 等. 安固里淖流域地下水水化学特征与水质评价[J]. 环境科学与技术, 2020,43(3):198-205.
[12]	胡云虎, 张付海, 钮志远, 等. 皖北地区集中式深层地下水饮用水源地水化学特征及水质评价[J]. 中国科学技术大学学报, 2014,44(11):913-920.
[13]	Raju N J. Hydrogeochemical parameters for assessment of groundwater quality in the upper Gunjanaeru river basin, Cuddapah district, Andhra Pradesh, south INDIA[J]. Environ Geol, 2007(52):1067-1074.
[14]	吕晓立, 刘景涛, 朱亮, 等. 甘肃省秦王川盆地地下水氟富集特征及影响因素[J]. 干旱区资源与环境, 2020,34(3):188-195.
[15]	田夏, 李亚松, 费宇红, 等. 滹沱河超采区地下水硫酸盐来源识别及迁移转化[J]. 科学技术与工程, 2020,20(7):2583-2589.
[16]	郑育林, 刘成, 雷声杨, 等. 我国部分地区高硬度地下水的水质特征及其处理需求分析[J]. 中国给水排水, 2018,34(18):12-17.

野外编号	K⁺	Na⁺	Ca²⁺	Mg²⁺		HCO₃^–		Cl^–		SO₄^2–		F^–		NO₃^–		总硬度		总碱度		偏硅酸		TDS	pH
B2684	1.30	71.2	10.5	5.61		180.5		7.16		27.7		0.25		2.51		49.2		164.1		19.5		241.1	8.33
B2399	0.60	86.6	10.1	4.39		212.4		20.1		30.4		0.47		0.30		43.2		174.2		15.4		270.7	7.73
B2666	1.10	79.1	10.9	7.32		175.6		25.8		44.9		0.35		6.51		57.3		144.0		16.2		276.1	7.79
B2565	0.20	102.5	2.82	0.49		175.6		20.4		32.3		0.99		0.30		9.0		176.2		15.3		278.6	8.29
B2560	6.80	101.7	2.01	0.49		77.3		24.0		33.6		0.70		0.30		7.0		168.1		20.5		286.7	8.38
B2566	0.20	103.8	8.45	0.98		220.4		19.7		30.6		0.98		0.30		25.1		180.8		18.0		288.8	7.91
B0610	0.20	110.0	3.62	0.49		199.2		20.4		32.9		0.97		0.30		11.1		186.6		16.1		294.5	8.43
B2611	0.40	104.1	6.04	1.95		192.7		30.8		29.3		0.59		0.30		23.1		182.2		14.8		295.4	8.40
B2480	0.50	102.5	6.84	0.49		168.6		31.2		34.8		0.57		3.96		19.1		173.0		15.1		297.6	8.32
B2396	0.70	68.4	24.6	10.3		205.0		26.5		48.5		0.35		2.51		103.5		168.1		22.9		301.9	7.74
B2661	0.90	108.4	9.26	2.44		251.7		17.2		28.9		0.20		6.79		33.2		206.4		17.6		313.4	7.89
B2657	1.15	72.2	21.3	16.1		222.2		38.0		27.4		0.33		12.88		119.6		182.2		18.5		314.7	7.45
B2385	1.20	89.5	14.1	12.2		227.5		33.3		26.4		0.35		11.85		85.4		186.6		16.1		315.0	7.90
B2397	0.60	90.7	16.5	8.79		227.1		30.1		42.2		0.39		3.70		77.4		186.2		17.4		319.9	7.76
B2659	1.00	80.8	18.1	13.2		222.2		33.3		33.8		0.42		14.21		99.5		182.2		18.3		320.1	7.92
B2414	1.30	92.9	13.6	5.56		191.8		39.3		48.2		0.23		14.84		56.7		157.3		18.9		326.4	8.17
B2422	1.85	60.1	35.0	15.4		220.6		9.64		95.4		0.33		2.39		150.9		180.9		23.6		348.6	8.18
B2655	0.50	63.0	36.6	22.5		256.6		38.0		47.1		0.42		5.58		183.9		210.4		22.6		359.3	7.78
B2380	0.90	85.5	23.7	12.9		187.8		51.9		68.2		0.47		8.38		112.6		154.0		18.0		359.7	7.74
B2386	0.40	99.7	20.5	11.7		206.3		63.4		47.1		0.68		0.30		99.5		169.2		18.3		360.7	7.84
B2563	0.30	120.8	12.5	2.93		189.8		55.9		67.4		0.64		0.30		43.2		155.6		17.3		368.6	7.73
B2610	0.30	118.7	14.1	5.86		246.8		38.0		58.1		0.69		0.30		59.3		202.4		18.1		373.0	7.73
B2660	1.40	63.2	43.9	25.4		273.8		41.2		62.2		0.21		6.00		214.1		224.5		24.2		398.9	7.78
B2394	0.50	97.2	20.5	23.4		300.8		16.5		74.4		0.69		1.26		147.8		246.7		20.9		401.0	7.80
B2665	0.40	114.8	23.7	9.28		273.8		46.6		56.7		0.64		0.30		97.5		224.5		20.1		404.4	7.72
B2564	0.30	147.1	15.7	4.88		187.8		52.6		141.1		0.61		0.30		59.3		154.0		14.7		467.5	8.02
B2599	0.80	68.9	47.5	42.2		381.8		32.9		66.5		0.39		22.82		292.5		313.1		25.7		492.7	7.95
B2384	2.30	105.7	34.6	35.6		423.5		47.6		51.9		0.49		1.22		233.2		347.3		21.8		508.0	7.35
B2389	0.30	144.8	26.6	20.5		308.1		63.4		122.9		0.96		0.30		150.8		252.7		18.3		547.6	7.81
B2486	0.60	151.0	36.6	29.8		303.0		77.7		172.6		0.92		3.11		214.1		248.4		18.4		638.0	7.41
B2398	0.40	135.6	51.9	40.5		408.8		94.5		119.0		0.40		0.30		296.5		335.2		22.3		663.9	7.51
B2662	0.50	95.5	84.1	54.7		470.2		128.2		65.8		0.81		2.90		435.2		385.6		23.9		686.0	7.16
B2383	7.50	139.2	43.1	40.8		241.7		87.0		245.7		0.42		1.88		275.4		198.2		20.6		702.2	7.58
B2382	0.40	91.2	107.0	77.9		570.9		145.0		111.7		0.85		0.30		588.0		468.1		24.6		838.4	7.10
B2415	0.50	160.3	56.6	66.9		362.1		155.7		213.9		0.58		1.50		417.0		296.9		21.8		853.8	7.87
B0482	0.60	119.4	107.4	57.2		489.8		91.7		222.9		1.06		0.56		504.0		401.7		21.7		862.6	7.23
B2481	0.20	286.9	14.1	19.5		399.6		99.9		231.3		2.38		0.30		115.6		327.7		14.7		865.4	8.04
B2654	0.50	150.2	55.1	83.5		681.4		73.8		121.6		0.73		21.08		481.5		558.7		26.3		867.4	7.12
B2487	0.30	273.7	25.4	22.9		397.3		133.6		213.5		1.37		0.30		157.8		325.8		16.6		882.1	7.46
B2390	0.30	106.4	131.6	68.4		621.3		142.9		126.9		1.15		0.30		610.1		509.5		22.0		905.1	7.26
B2395	0.80	181.2	57.5	73.7		676.4		82.4		139.8		1.00		16.43		447.3		554.7		23.6		909.3	7.55
B2392	0.40	204.5	56.7	57.1	472.7		109.9		245.6		1.45		0.30		376.9		387.7		20.1		927.6		7.48
B2381	0.50	148.2	93.0	89.3	607.1		146.5		169.7		1.09		34.13		600.0		497.9		21.8		1002.7		7.28
B2656	0.70	107.0	134.0	99.1	779.6		84.5		188.6		0.72		21.27		742.8		639.3		27.7		1047.0		7.02
B0480	0.50	244.6	51.9	68.1	465.3		133.6		348.4		1.00		0.30		410.1		381.6		17.7		1094.3		7.55

野外编号	K⁺	Na⁺	Ca²⁺	Mg²⁺		HCO₃^–		Cl^–		SO₄^2–		F^–		NO₃^–		总硬度		总碱度		偏硅酸		TDS	pH
B2684	1.30	71.2	10.5	5.61		180.5		7.16		27.7		0.25		2.51		49.2		164.1		19.5		241.1	8.33
B2399	0.60	86.6	10.1	4.39		212.4		20.1		30.4		0.47		0.30		43.2		174.2		15.4		270.7	7.73
B2666	1.10	79.1	10.9	7.32		175.6		25.8		44.9		0.35		6.51		57.3		144.0		16.2		276.1	7.79
B2565	0.20	102.5	2.82	0.49		175.6		20.4		32.3		0.99		0.30		9.0		176.2		15.3		278.6	8.29
B2560	6.80	101.7	2.01	0.49		77.3		24.0		33.6		0.70		0.30		7.0		168.1		20.5		286.7	8.38
B2566	0.20	103.8	8.45	0.98		220.4		19.7		30.6		0.98		0.30		25.1		180.8		18.0		288.8	7.91
B0610	0.20	110.0	3.62	0.49		199.2		20.4		32.9		0.97		0.30		11.1		186.6		16.1		294.5	8.43
B2611	0.40	104.1	6.04	1.95		192.7		30.8		29.3		0.59		0.30		23.1		182.2		14.8		295.4	8.40
B2480	0.50	102.5	6.84	0.49		168.6		31.2		34.8		0.57		3.96		19.1		173.0		15.1		297.6	8.32
B2396	0.70	68.4	24.6	10.3		205.0		26.5		48.5		0.35		2.51		103.5		168.1		22.9		301.9	7.74
B2661	0.90	108.4	9.26	2.44		251.7		17.2		28.9		0.20		6.79		33.2		206.4		17.6		313.4	7.89
B2657	1.15	72.2	21.3	16.1		222.2		38.0		27.4		0.33		12.88		119.6		182.2		18.5		314.7	7.45
B2385	1.20	89.5	14.1	12.2		227.5		33.3		26.4		0.35		11.85		85.4		186.6		16.1		315.0	7.90
B2397	0.60	90.7	16.5	8.79		227.1		30.1		42.2		0.39		3.70		77.4		186.2		17.4		319.9	7.76
B2659	1.00	80.8	18.1	13.2		222.2		33.3		33.8		0.42		14.21		99.5		182.2		18.3		320.1	7.92
B2414	1.30	92.9	13.6	5.56		191.8		39.3		48.2		0.23		14.84		56.7		157.3		18.9		326.4	8.17
B2422	1.85	60.1	35.0	15.4		220.6		9.64		95.4		0.33		2.39		150.9		180.9		23.6		348.6	8.18
B2655	0.50	63.0	36.6	22.5		256.6		38.0		47.1		0.42		5.58		183.9		210.4		22.6		359.3	7.78
B2380	0.90	85.5	23.7	12.9		187.8		51.9		68.2		0.47		8.38		112.6		154.0		18.0		359.7	7.74
B2386	0.40	99.7	20.5	11.7		206.3		63.4		47.1		0.68		0.30		99.5		169.2		18.3		360.7	7.84
B2563	0.30	120.8	12.5	2.93		189.8		55.9		67.4		0.64		0.30		43.2		155.6		17.3		368.6	7.73
B2610	0.30	118.7	14.1	5.86		246.8		38.0		58.1		0.69		0.30		59.3		202.4		18.1		373.0	7.73
B2660	1.40	63.2	43.9	25.4		273.8		41.2		62.2		0.21		6.00		214.1		224.5		24.2		398.9	7.78
B2394	0.50	97.2	20.5	23.4		300.8		16.5		74.4		0.69		1.26		147.8		246.7		20.9		401.0	7.80
B2665	0.40	114.8	23.7	9.28		273.8		46.6		56.7		0.64		0.30		97.5		224.5		20.1		404.4	7.72
B2564	0.30	147.1	15.7	4.88		187.8		52.6		141.1		0.61		0.30		59.3		154.0		14.7		467.5	8.02
B2599	0.80	68.9	47.5	42.2		381.8		32.9		66.5		0.39		22.82		292.5		313.1		25.7		492.7	7.95
B2384	2.30	105.7	34.6	35.6		423.5		47.6		51.9		0.49		1.22		233.2		347.3		21.8		508.0	7.35
B2389	0.30	144.8	26.6	20.5		308.1		63.4		122.9		0.96		0.30		150.8		252.7		18.3		547.6	7.81
B2486	0.60	151.0	36.6	29.8		303.0		77.7		172.6		0.92		3.11		214.1		248.4		18.4		638.0	7.41
B2398	0.40	135.6	51.9	40.5		408.8		94.5		119.0		0.40		0.30		296.5		335.2		22.3		663.9	7.51
B2662	0.50	95.5	84.1	54.7		470.2		128.2		65.8		0.81		2.90		435.2		385.6		23.9		686.0	7.16
B2383	7.50	139.2	43.1	40.8		241.7		87.0		245.7		0.42		1.88		275.4		198.2		20.6		702.2	7.58
B2382	0.40	91.2	107.0	77.9		570.9		145.0		111.7		0.85		0.30		588.0		468.1		24.6		838.4	7.10
B2415	0.50	160.3	56.6	66.9		362.1		155.7		213.9		0.58		1.50		417.0		296.9		21.8		853.8	7.87
B0482	0.60	119.4	107.4	57.2		489.8		91.7		222.9		1.06		0.56		504.0		401.7		21.7		862.6	7.23
B2481	0.20	286.9	14.1	19.5		399.6		99.9		231.3		2.38		0.30		115.6		327.7		14.7		865.4	8.04
B2654	0.50	150.2	55.1	83.5		681.4		73.8		121.6		0.73		21.08		481.5		558.7		26.3		867.4	7.12
B2487	0.30	273.7	25.4	22.9		397.3		133.6		213.5		1.37		0.30		157.8		325.8		16.6		882.1	7.46
B2390	0.30	106.4	131.6	68.4		621.3		142.9		126.9		1.15		0.30		610.1		509.5		22.0		905.1	7.26
B2395	0.80	181.2	57.5	73.7		676.4		82.4		139.8		1.00		16.43		447.3		554.7		23.6		909.3	7.55
B2392	0.40	204.5	56.7	57.1	472.7		109.9		245.6		1.45		0.30		376.9		387.7		20.1		927.6		7.48
B2381	0.50	148.2	93.0	89.3	607.1		146.5		169.7		1.09		34.13		600.0		497.9		21.8		1002.7		7.28
B2656	0.70	107.0	134.0	99.1	779.6		84.5		188.6		0.72		21.27		742.8		639.3		27.7		1047.0		7.02
B0480	0.50	244.6	51.9	68.1	465.3		133.6		348.4		1.00		0.30		410.1		381.6		17.7		1094.3		7.55

项目	K⁺	Na⁺	Ca²⁺	Mg²⁺	HCO₃^-	Cl^-	SO₄^2-
极小值	0.20	60.1	2.01	0.49	77.3	7.16	26.4
极大值	7.50	286.9	134.0	99.1	779.5	155.7	348.4
平均值	0.96	118.9	36.4	28.3	323.4	61.4	98.8
标准差	1.42	51.5	33.8	28.4	165.0	42.9	78.8
变异系数CV/%	148.7	43.3	92.8	100.4	51.0	70.0	79.7
项目	F^-	NO₃^-	总硬度	总碱度	偏硅酸	TDS	pH
极小值	0.20	0.30	7.03	168.1	14.7	241.1	7.02
极大值	2.38	34.1	742.8	639.3	27.7	1094.3	8.43
平均值	0.70	5.24	207.5	270.5	19.7	530.6	7.74
标准差	0.40	7.75	195.9	130.2	3.39	265.6	0.37
变异系数CV/%	58.1	147.9	94.5	48.2	17.2	50.1	4.8

项目	K⁺	Na⁺	Ca²⁺	Mg²⁺	HCO₃^-	Cl^-	SO₄^2-
极小值	0.20	60.1	2.01	0.49	77.3	7.16	26.4
极大值	7.50	286.9	134.0	99.1	779.5	155.7	348.4
平均值	0.96	118.9	36.4	28.3	323.4	61.4	98.8
标准差	1.42	51.5	33.8	28.4	165.0	42.9	78.8
变异系数CV/%	148.7	43.3	92.8	100.4	51.0	70.0	79.7
项目	F^-	NO₃^-	总硬度	总碱度	偏硅酸	TDS	pH
极小值	0.20	0.30	7.03	168.1	14.7	241.1	7.02
极大值	2.38	34.1	742.8	639.3	27.7	1094.3	8.43
平均值	0.70	5.24	207.5	270.5	19.7	530.6	7.74
标准差	0.40	7.75	195.9	130.2	3.39	265.6	0.37
变异系数CV/%	58.1	147.9	94.5	48.2	17.2	50.1	4.8
