Comparative Study on Tetraploid Induction of Taraxacum kok-saghyz Rodin with Oryzalin and Colchicine

doi:10.11924/j.issn.1000-6850.casb2020-0581

Abstract

Abstract:

To explore the induction effect of different mutagens on Taraxacum kok-saghyz Rodin (TKS), the seedlings of TKS were used as materials, the polyploid induction effects of different concentrations and treatment time of oryzalin and colchicine on TKS were analyzed, and the changes of morphological characteristics of polyploid TKS were studied using the buds soaking method. The results showed that, the seedling rate (60%-75%) and the highest mutation rate (14.08%) of the TKS treated with oryzalin were both higher than those of colchicine (0-59% and 5.56%), respectively. The chimera rate (27.27%) treated with oryzalin was lower than that of colchicine (75.00%). The treatment with 0.04 mmol/L oryzalin for 30 min was the optimal condition for TKS tetraploid induction, the seedling rate was 71.00% and the induction rate was 14.08%. Therefore, colchicine was more suitable for TKS polyploid induction than colchicine. The leaf thickness, stomata size in the lower epidermis, flower size and seed size of tetraploid TKS plants were significantly larger than those of wild-type diploid plants, and stomatal density was significantly less than that of wild-type plants. These morphological characteristics could assist the rapid screening and identification of polyploid TKS. The induction effect of two mutagens on TKS was preliminarily explored in this study, which could provide a theoretical basis and technical support for TKS polyploid breeding in the future.

Key words: Taraxacum kok-saghyz Rodin (TKS), oryzalin, colchicine, tetraploid, polyploid induction

CLC Number:

S576

Yang Yushuang, Qin Bi, Zhang Jichuan, Zhang Liqun, Nie Qiuhai, Liu Shizhong. Comparative Study on Tetraploid Induction of Taraxacum kok-saghyz Rodin with Oryzalin and Colchicine[J]. Chinese Agricultural Science Bulletin, 2021, 37(20): 35-41.

Figures/Tables 5

References 30

[1]	林伯煌,魏小弟.橡胶草的研究进展[J].安徽农业科学,2009,37(13):5950-5951.
[2]	罗士苇,吴相钰,冯午.橡胶草的研究部分II-新疆产橡胶草的化学分析及其橡胶含量之测定[J].中国科学,1951,2(3):381-387.
[3]	张立群.天然橡胶及生物基弹性体[M]:北京:化学工业出版社,2014.
[4]	张慧艳,杨青哲,杨露露,等.橡胶草(Taraxacum kok-saghyz Rodin)小橡胶粒子蛋白基因的克隆与表达分析[J].北方园艺,2019,14:32-39.
[5]	van Beilen J B,Poirier Y.Establishment of new crops for the production of natural rubber[J].Trends in Biotechnology,2007,25(11):522-529. pmid: 17936926
[6]	谢全亮,李鸿彬,王旭初.橡胶草90年来主要研究成果及最新研究进展[J].植物科学学报,2019,37(3):404-412.
[7]	仇建,张继川,罗世巧,等.橡胶草的研究进展[J].植物学报,2015,50(1):133-141.
[8]	王肖肖,覃碧,杨玉双,等.橡胶草的遗传改良研究进展[J].分子植物育种,2020,18(17):5826-5834.
[9]	Sattler M C,Carvalho C R,Clarindo W R.The polyploidy and its key role in plant breeding[J].Planta,2016,243:281-296. doi: 10.1007/s00425-015-2450-x URL
[10]	Han P P,Liu W X,Liang H H,et al.In vitro induction and identification of autotetraploid of Bletilla striata (Thunb.) Reichb.f. by colchicine treatment[J].Plant Cell, Tissue and Organ Culture,2018,132:425-432. doi: 10.1007/s11240-017-1339-8 URL
[11]	斯契潘诺夫.橡胶草栽培法[M].沈阳:东北农业出版社,1952.
[12]	Warmke H E.Experimental polyploidy and rubber content in Taraxacum koksaghyz[J].Botanical Gazette,1945,106:316-324. doi: 10.1086/335301 URL
[13]	Luo Z N,Iaffaldano B J,Cornish K.Colchicine-induced polyploidy has the potential to improve rubber yield in Taraxacum kok-saghyz[J].Industrial Crops & Products,2018,112:75-81.
[14]	安飞飞,凡杰,李庚虎,等.华南8号木薯及其四倍体诱导株系叶片蛋白质组及叶绿素荧光差异分析[J].中国农业科学,2013,46(19):3978-3987.
[15]	王红娟,杨岚,李雅婷,等.茅苍术同源四倍体离体诱导与鉴定[J].核农学报,2015,29(6):1030-1036.
[16]	刘欢,高素萍,姜福星,等.二甲戊灵与秋水仙素离体诱导虎眼万年青多倍体发生的比较研究[J].核农学报,2014,28(11):1985-1992.
[17]	储丽红,彭佳佳,王钊,等.氨磺灵、氟乐灵和秋水仙素诱导安祖花多倍体的研究[J].园艺学报,2014,41(11):2275-2280.
[18]	黄权军.化学药剂诱导植物多倍体研究进展[J].安徽农学通报,2009,15(5):58-59.
[19]	邵果园,郑伟尉,徐凯.新型诱变剂“Oryzalin”在园艺植物倍性育种上的应用[J].中国南方果树,2013,42(6):24-27.
[20]	Chung M Y,Kim C Y,Min J S,et al.In vitro induction of tetraploids in an interspecific hybrid of Calanthe (Calanthe discolor × Calanthe sieboldii) through colchicine and oryzalin treatments[J].Plant Biotechnology Reports,2014,8(3):251-257. doi: 10.1007/s11816-014-0317-4 URL
[21]	Lam H K,Harbard J L,Koutoulis A.Tetraploid induction of acacia crassicarpa using colchicine and oryzalin[J].Journal of Tropical Forest Science,2014,26(3):347-354.
[22]	孔素萍,段乃彬,刘冰江,等.不同诱变剂对大蒜四倍体诱导的影响[J].核农学报,2016,30(6):1067-1073.
[23]	Sakhanokho H F,Rajasekaran K,Kelley R Y,et al.Induced polyploidy in diploid ornamental ginger (Hedychium muluense R. M. Smith) using colchicine and oryzalin[J].Hortscience,2009,44(7):1809-1814. doi: 10.21273/HORTSCI.44.7.1809 URL
[24]	阎志红,刘文革,赵胜杰,等.利用二硝基苯胺类除草剂离体诱导西瓜四倍体[J].园艺学报,2008,35(11):1621-1626.
[25]	康向阳,王君.杨树多倍体诱导技术研究[M].北京:科学出版社,2010.
[26]	杨玉双,甘霖,覃碧,等.橡胶草染色体制片技术研究[J].热带农业科学,2017,37(2):31-34.
[27]	赵璘,刘文革,郭金丽,等.除草剂在植物离体染色体加倍上的应用[J].长江农业,2008(1):30-32.
[28]	张虹,龙宏周,路国栋,等.黑果枸杞多倍体诱导及鉴定[J].核农学报,2017,31(1):59-65.
[29]	彭绿春,陶俊锋,段修安,等.腋花杜鹃多倍体诱导和鉴定[J].核农学报,2018,32(2):257-265.
[30]	汪艳,肖媛,刘伟,等.流式细胞仪检测高等植物细胞核DNA含量的方法[J].植物科学学报,2015,33(1):126-131.

处理药剂	处理浓度	处理时间	处理株数	成苗株数	成苗率/%	变异株数		诱导率/%	嵌合体率/%
处理药剂	处理浓度	处理时间	处理株数	成苗株数	成苗率/%	四倍体数	嵌合体数	诱导率/%	嵌合体率/%
CK		30 min	100	100	100.00	0	0	0.00	0.00
秋水仙素	0.05%	30 min	100	59	59.00	1	1	3.39	75.00
		1 h	100	50	50.00	0	1	2.00
		2 h	100	51	51.00	0	1	1.96
		4 h	100	46	46.00	0	0	0
		8 h	100	39	39.00	0	0	0
	0.10%	30 min	100	36	36.00	0	2	5.56
		1 h	100	38	38.00	1	0	2.63
		2 h	100	41	41.00	0	1	2.43
		4 h	100	28	28.00	0	0	0
		8 h	100	25	25.00	0	0	0
	0.20%	30 min	100	37	37.00	0	0	0
		1 h	100	0	0.00	0	0	0
		2 h	100	0	0.00	0	0	0
		4 h	100	0	0.00	0	0	0
		8 h	100	0	0.00	0	0	0
氨磺灵	0.01 mmol/L	30 min	100	75	75.00	2	1	4.00	27.27
		1 h	100	70	70.00	1	1	2.84
		2 h	100	70	70.00	1	0	1.42
		4 h	100	69	69.00	1	0	1.45
		8 h	100	60	60.00	0	0	0
	0.02 mmol/L	30 min	100	71	71.00	2	1	4.23
		1 h	100	69	69.00	2	0	2.90
		2 h	100	63	63.00	1	0	1.59
		4 h	100	63	63.00	1	0	1.59
		8 h	100	60	60.00	0	0	0
	0.04 mmol/L	30 min	100	71	71.00	8	2	14.08
		1 h	100	71	71.00	3	2	7.04
		2 h	100	69	69.00	1	2	4.35
		4 h	100	69	69.00	1	1	2.90
		8 h	100	68	68.00	2	0	2.94
	0.08 mmol/L	30 min	100	72	72.00	3	1	5.56
		1 h	100	71	71.00	2	1	4.23
		2 h	100	70	70.00	2	1	4.17
		4 h	100	68	68.00	0	0	0
		8 h	100	61	61.00	0	0	0

处理药剂	处理浓度	处理时间	处理株数	成苗株数	成苗率/%	变异株数		诱导率/%	嵌合体率/%
处理药剂	处理浓度	处理时间	处理株数	成苗株数	成苗率/%	四倍体数	嵌合体数	诱导率/%	嵌合体率/%
CK		30 min	100	100	100.00	0	0	0.00	0.00
秋水仙素	0.05%	30 min	100	59	59.00	1	1	3.39	75.00
		1 h	100	50	50.00	0	1	2.00
		2 h	100	51	51.00	0	1	1.96
		4 h	100	46	46.00	0	0	0
		8 h	100	39	39.00	0	0	0
	0.10%	30 min	100	36	36.00	0	2	5.56
		1 h	100	38	38.00	1	0	2.63
		2 h	100	41	41.00	0	1	2.43
		4 h	100	28	28.00	0	0	0
		8 h	100	25	25.00	0	0	0
	0.20%	30 min	100	37	37.00	0	0	0
		1 h	100	0	0.00	0	0	0
		2 h	100	0	0.00	0	0	0
		4 h	100	0	0.00	0	0	0
		8 h	100	0	0.00	0	0	0
氨磺灵	0.01 mmol/L	30 min	100	75	75.00	2	1	4.00	27.27
		1 h	100	70	70.00	1	1	2.84
		2 h	100	70	70.00	1	0	1.42
		4 h	100	69	69.00	1	0	1.45
		8 h	100	60	60.00	0	0	0
	0.02 mmol/L	30 min	100	71	71.00	2	1	4.23
		1 h	100	69	69.00	2	0	2.90
		2 h	100	63	63.00	1	0	1.59
		4 h	100	63	63.00	1	0	1.59
		8 h	100	60	60.00	0	0	0
	0.04 mmol/L	30 min	100	71	71.00	8	2	14.08
		1 h	100	71	71.00	3	2	7.04
		2 h	100	69	69.00	1	2	4.35
		4 h	100	69	69.00	1	1	2.90
		8 h	100	68	68.00	2	0	2.94
	0.08 mmol/L	30 min	100	72	72.00	3	1	5.56
		1 h	100	71	71.00	2	1	4.23
		2 h	100	70	70.00	2	1	4.17
		4 h	100	68	68.00	0	0	0
		8 h	100	61	61.00	0	0	0

形态特征	参数	二倍体(2×)	四倍体(4×)
气孔	气孔密度/(No/mm²)	39	30^**
	气孔长/μm	16.87	20.67^**
	气孔宽/μm	6.77	9.07^*
叶片形态	叶片长度/cm	14.64	14.39
	叶片宽度/cm	2.51	2.48
	叶厚度/mm	0.77	1.43^**
	叶型指数	5.89	5.82
花	花苞长度/cm	1.72	1.75
	花苞直径/cm	2.68	3.31^**
	花柄直径 /mm	1.55	2.12^**
种子	粒长/cm	0.48	0.66^**
种子	粒宽/cm	0.12	0.17^**

形态特征	参数	二倍体(2×)	四倍体(4×)
气孔	气孔密度/(No/mm²)	39	30^**
	气孔长/μm	16.87	20.67^**
	气孔宽/μm	6.77	9.07^*
叶片形态	叶片长度/cm	14.64	14.39
	叶片宽度/cm	2.51	2.48
	叶厚度/mm	0.77	1.43^**
	叶型指数	5.89	5.82
花	花苞长度/cm	1.72	1.75
	花苞直径/cm	2.68	3.31^**
	花柄直径 /mm	1.55	2.12^**
种子	粒长/cm	0.48	0.66^**
种子	粒宽/cm	0.12	0.17^**
