神府矿区土地利用与NDVI时空变化及其驱动因素分析

doi:10.11924/j.issn.1000-6850.casb2020-0196

摘要/Abstract

摘要：

旨在研究矿区人类活动引起的土地利用变化及其对植被指数变化影响。以陕西省神府矿区为研究范围,应用线性趋势法和相关系数,结合土地利用和MODIS NDVI数据,分析了神府矿区土地利用与NDVI时空变化过程及其驱动因素。结果表明,2000—2010年神府矿区土地利用变化特征表现为耕地大面积转为草地和建设用地迅速增加。2000—2015年神府矿区NDVI总体呈线性增加趋势,线性增加速率为0.105/10a(P<0.001)。NDVI显著增加区域占矿区总面积的95.95%,仅有河流谷地、城镇附近区域NDVI呈减少趋势。耕地面积下降和建设用地面积扩张,导致NDVI降低,草地和林地面积增加,引起NDVI升高。神府矿区2000—2015年NDVI与气温以负相关为主,与降水以显著正相关为主,占区域总面积的97.79%,负相关以斑块状和线状集中在城镇附近和河流谷地。研究认为退耕还林还草工程实施和社会经济发展引起的城市扩张是神府矿区土地利用变化的主要驱动因素,而气候变化尤其是降水增加和草地、林地面积增加有力促进了NDVI的升高。

关键词: 自然地理学, 土地利用, 线性趋势法, 退耕还林还草, 神府矿区

Abstract:

The aim is to study land use changes caused by human activities in mining areas and their impact on vegetation index changes. Taking Shenfu mining area in Shaanxi Province as the research scope, combing with the comprehensive land use and MODIS NDVI data, the temporal and spatial variation process and driving factors of land use and NDVI were analyzed with linear trend method and correlation coefficients. The results showed that the characteristics of land use change from 2000 to 2010 were the conversion of large areas of farmland to grassland and rapid increase of construction land. From 2000 to 2015, NDVI showed a linear increase trend and the linear increase rate was 0.105/10a (P<0.001). The NDVI significantly increased area accounted for 95.95% of the total area, while only the river valley and the area near the town showed a decreasing trend. The decline area of farmland and the expansion area of construction land led to the decrease of NDVI, but the increase area in grassland and woodland resulted in the increase of NDVI. NDVI from 2000 to 2015 was mainly negatively correlated with temperature, and was significantly and positively correlated with precipitation, accounting for 97.79% of the total area. The negative correlation was concentrated in the vicinity of towns and river valleys by plaques and lines. The study indicates that urban expansion caused by social and economic development and the grain for green project implementation are the main driving factors for land use change in Shenfu mining area, and climate change, especially the increase of precipitation and the increase of grassland and forest land area, has promoted the increase of NDVI.

Key words: physical geography, land use, linear change analysis, grain for green project, Shenfu mining area

中图分类号:

S718.57

夏正清, 谢艳玲, 王涛. 神府矿区土地利用与NDVI时空变化及其驱动因素分析[J]. 中国农学通报, 2021, 37(14): 97-105.

Xia Zhengqing, Xie Yanling, Wang Tao. Land Use and Spatial and Temporal Change of Normalized Difference Vegetation Index (NDVI) in Shenfu Mining Area and Their Driving Factors Analysis[J]. Chinese Agricultural Science Bulletin, 2021, 37(14): 97-105.

图/表 8

参考文献 26

[1]	Arifasihati Y, Kaswanto. Analysis of land use and cover changes in Clawing and Cicadae watershed in three decades[J]. Procedia Environmental Science, 2016,33:465-469. doi: 10.1016/j.proenv.2016.03.098 URL
[2]	Zheng L, Yang S, Zhang M. Study on land use change in arid and semiarid region based on GIS and RS[J]. Information Technology Journal, 2014,13(8):1567-1571. doi: 10.3923/itj.2014.1567.1571 URL
[3]	Tian Y, Bai X, Wang S, et al. Spatial-temporal changes of vegetation cover in Guizhou province, southern China[J]. Chinese Geographical Science, 2017,27(1):25-38. doi: 10.1007/s11769-017-0844-3 URL
[4]	Gao C, Zhou P, Jia P, et al. Spatial driving forces of dominant land use/land cover transformations in the Dongjiang river watershed, southern China[J]. Environmental Monitoring and Assessment, 2016,188(2):84. doi: 10.1007/s10661-015-5088-z URL
[5]	Gu W, Guo J, Fan K, et al. Dynamic land use change and sustainable urban development in a Third-tier city within Yangtze delta[J]. Procedia Environmental Science, 2016,36:98-105. doi: 10.1016/j.proenv.2016.09.019 URL
[6]	Turner B L, Geoghegan J, Lawrence D, et al. Land system science and the social-environmental system: the case of southern Yucatán peninsular region (SYPR) project[J]. Current Opinion in Environmental Sustainability, 2016,19:18-29. doi: 10.1016/j.cosust.2015.08.014 URL
[7]	Li J, Liu H, Liu Yong, et al. Land use and land cover change processes in China’s eastern Loess Plateau[J]. Science in Cold and Arid Regions, 2015,7(6):722-729.
[8]	Sun B, Zhou Q. Expressing the spatio-temporal pattern of farmland change in arid lands using landscape metrics[J]. Journal of Arid Environments, 2016,124:118-127. doi: 10.1016/j.jaridenv.2015.08.007 URL
[9]	Chen H, Kenyon J M, Carr D L, et al. Land cover and landscape changes in Shaanxi province during China’s grain for green program (2000-2010)[J]. Environmental Monitoring and Assessment, 2015,187(10):644. doi: 10.1007/s10661-015-4881-z pmid: 26407858
[10]	Fan Q, Ding S. Landscape pattern changes at a county scale: a case study in Fengqiu, Henan province, China from 1990 to 2013[J]. Catena, 2016,137:152-160. doi: 10.1016/j.catena.2015.09.012 URL
[11]	Lu J, Dong Z, Hu G, et al. Land use and land cover change and its driving forces in Maqu County, China in the past 25 years[J]. Science in Cold and Arid Regions, 2016,8(5):432-440.
[12]	Ye Y, Zhang H, Liu K, et al. Research on the influence of site factors on the expansion of construction land in the Pearl River Delta, China: by using GIS and remote sensing[J]. International Journal of Applied Earth Observation and Geoinformation, 2013,21:366-373. doi: 10.1016/j.jag.2011.10.012 URL
[13]	Shao Y, Taff G N, Ren J, et al characterizing major agricultural land change trends in the western Corn Belt[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2016,122:116-125. doi: 10.1016/j.isprsjprs.2016.10.009 URL
[14]	Chen R, Ye C, Cai Y, et al. The impact of rural out-migration on land use transition in China: past, present and trend[J]. Land Use Policy, 2014,40, 101-110. doi: 10.1016/j.landusepol.2013.10.003 URL
[15]	Xu X, Du Z, Zhang H. Integrating the system dynamic and cellular automata models to predict land use and land cover change[J]. International Journal of Applied Earth Observation and Geoinformation, 2016,52:568-579. doi: 10.1016/j.jag.2016.07.022 URL
[16]	Hu Y, Zheng Y, Zheng X. Simulation of land-use scenarios for Beijing using CLUE-S and Markov composite models[J]. Chinese Geographical Science, 2013,23(1):92-100. doi: 10.1007/s11769-013-0594-9 URL
[17]	Wang H, Kong X, Zhang B. The simulation of LUCC based on Logistic-CA-Markov model in Qilian Mountain area, China[J]. Science in Cold and Arid Regions, 2016,8(4):350-358.
[18]	Schirpke U, Leitinger G, Tappeiner U, et al. SPA-LUCC: developing land-use/cover scenarios in mountain landscapes[J]. Ecological Informatics, 2012,12:68-76. doi: 10.1016/j.ecoinf.2012.09.002 URL
[19]	Xing Z, Shi X, Yan D, et al. Analysis of land use dynamics and landscape pattern change in the Huai river basin, China[J]. Journal of Food, Agriculture & Environment, 2013,11(3&4):1933-1938.
[20]	韩召迎, 孟亚利, 刘丽平, 等. 基于区域土地利用变化的能源碳足迹改进算法及应用[J]. 农业工程学报, 2012,28(9):190-195.
[21]	Smith P, House J I, Bustamante M, et al. Global change pressures on soils from land use and management[J]. Global Change Biology, 2016,22(3):1008-1028. doi: 10.1111/gcb.13068 pmid: 26301476
[22]	Song W, Deng X, Yuan Y, et al. Impacts of land-use change on valued ecosystem service in rapidly urbanized North China Plain[J]. Ecological modelling, 2015,318:245-253. doi: 10.1016/j.ecolmodel.2015.01.029 URL
[23]	Liu P, Zheng X, Chen J, et al. Characteristic analysis of ecosystem service value of water system in Taiyuan urban district based on LUCC[J]. International Journal of Agricultural and Biological Engineering, 2016,9(1):153-165.
[24]	徐建华. 计量地理学(第二版)[M]. 北京: 高等教育出版社, 2014: 84-106.
[25]	张元栋, 尚晓鹏, 杜芬玲, 等. 宁夏植被动态变化及其对降水的响应[J]. 西安科技大学学报, 2017,37(1):84-89.
[26]	Gandhi G M, Parthiban S, Thummalu N, et al. NDVI: vegetation change detection using remote sensing and GIS-A case study of Vellore District[J]. Procedia Computer Science, 2015,57:1199-1210. doi: 10.1016/j.procs.2015.07.415 URL

类型	林地	草地	水域	耕地	建设用地	未利用地
林地	223.73/98.34	0.08/0.04	0.00/0.00	0.00/0.00	3.37/1.48	0.32/0.14
草地	13.81/0.22	6275.95/98.31	0.64/0.01	0.27/0.00	92.25/1.45	1.09/0.02
水域	0.30/0.40	1.23/1.66	59.86/80.32	4.01/5.38	0.48/0.65	8.64/11.59
耕地	1.47/0.08	430.80/22.24	1.65/0.09	1472.38/76.01	27.16/1.40	3.71/0.19
建设用地	0.00/0.00	0.00/0.00	0.00/0.00	0.00/0.00	82.05/100.00	0.00/0.00
未利用地	1.55/0.08	9.56/0.49	3.46/0.18	2.46/0.12	43.69/2.22	1907.14/96.92

类型	林地	草地	水域	耕地	建设用地	未利用地
林地	223.73/98.34	0.08/0.04	0.00/0.00	0.00/0.00	3.37/1.48	0.32/0.14
草地	13.81/0.22	6275.95/98.31	0.64/0.01	0.27/0.00	92.25/1.45	1.09/0.02
水域	0.30/0.40	1.23/1.66	59.86/80.32	4.01/5.38	0.48/0.65	8.64/11.59
耕地	1.47/0.08	430.80/22.24	1.65/0.09	1472.38/76.01	27.16/1.40	3.71/0.19
建设用地	0.00/0.00	0.00/0.00	0.00/0.00	0.00/0.00	82.05/100.00	0.00/0.00
未利用地	1.55/0.08	9.56/0.49	3.46/0.18	2.46/0.12	43.69/2.22	1907.14/96.92
