Effects of Different Drip Irrigation Belt Deployment Methods on Nutrient Distribution and Utilization Characteristics of Apple-Soybean Alley Cropping System

doi:10.11924/j.issn.1000-6850.casb2022-0355

Abstract

Abstract:

To investigate the effects of different drip irrigation belt deployment methods on soil and plant nutrient distribution and utilization characteristics in an alley cropping system, a split-zone experiment was carried out to analyze the spatial distribution of soil nutrients, soybean yield, plant nutrient uptake and use efficiency in a typical apple-soybean intercropping system under different drip irrigation belt deployment. Three types of drip belt spacing (L1: drip belt at the root of each soybean row; L2: one drip belt every other soybean row; L3: two drip belts every three soybean rows) and two types of mulching (M1: white film and M0: without film) were applied. The results showed that mulching type and drip irrigation belt layout had significant effects on the distribution of soil nutrients (P<0.05). In the horizontal direction, the variation trend of soil nutrient content in different distances from tree rows showed “V” and “N” shape patterns. By means of the drip belt layout, soil water and fertilizer could be redistributed, hence to promote the niche separation and alleviate competition between the two species as well, which could further improve the nutrient uptake and utilization efficiency to increase the yield ultimately. The highest plant nutrient content and uptake and utilization efficiency were both achieved in the treatment of white film mulching with one drip irrigation belt every other soybean row layout, under which the highest yield was 1747.6 kg/hm². The model could provide reference for alleviating the interspecific water-fertilizer competition in apple-soybean intercropping system.

Key words: alley cropping system, drip irrigation belt deployment, interspecific competition, soil nutrients, Loess Plateau of west Shanxi Province

WAN Qian, WANG Ruoshui, XIAO Wan, LUO Chengwei, DOU Xiaoyu, WANG Lisha, XIONG Chang, WANG Xin, DAI Houshuai. Effects of Different Drip Irrigation Belt Deployment Methods on Nutrient Distribution and Utilization Characteristics of Apple-Soybean Alley Cropping System[J]. Chinese Agricultural Science Bulletin, 2023, 39(11): 64-73.

Figures/Tables 10

References 30

[1]	云雷. 晋西黄土区果农间作系统种间关系研究[D]. 北京: 北京林业大学, 2011:5-25.
[2]	JOSE S, GILLESPIE A R, SEIFERT J R, et al. Defining competition vectors in a temperate alley cropping system in the midwestern USA: 3. Competition for nitrogen and litter decomposition dynamics[J]. Agroforestry Systems, 2000, 48(1):61-77. doi: 10.1023/A:1006241406462 URL
[3]	RAO M R, ONG C K, PATHAK P, et al. Productivity of annual cropping and agroforestry systems on a shallow Alfisol in semi-arid India[J]. Agroforestry Systems, 1991, 15(1):51-63. doi: 10.1007/BF00046278 URL
[4]	SANCHEZ P A. Science in agroforestry[J]. Agroforestry Systems, 1995, 30(1-2):5-55. doi: 10.1007/BF00708912 URL
[5]	FRIDAY J B, FOWNES J H. Competition for light between hedgerows and maize in an alley cropping system in Hawaii, USA[J]. Agroforestry Systems, 2002, 55(2):125-137. doi: 10.1023/A:1020598110484 URL
[6]	高飞, 王若水, 许华森. 晋西黄土区水肥调控对苹果玉米间作系统土壤含水量及分布的影响[J]. 中国水土保持科学, 2016, 14(4):94-104.
[7]	JOSE S, GILLESPIE A R, PALLARDY S G. Interspecific interactions in temperate agroforestry[J]. Agroforsyst, 2004, 61(1):237-255.
[8]	冯良山, 孙占祥, 郑家明, 等. 不同水肥条件对间作花生和谷子水分养分利用的影响[J]. 干旱地区农业研究, 2015, 33(5):24-29.
[9]	李发永, 张营山, 王龙, 等. 枣棉间作模式下作物不同水肥界面交互影响初探[J]. 干旱地区农业研究, 2014, 32(2):99-106,136.
[10]	尹飞, 毛任钊, 傅伯杰, 等. 枣粮间作生态系统土壤氮空间分布特性[J]. 生态学报, 2009, 29(1):325-331.
[11]	秦树高, 吴斌, 张宇清, 等. 林草复合系统地下部分种间互作关系与化感作用研究进展[J]. 草业学报, 2011, 20(2):253-261.
[12]	GOYAL S, CHANDER K, MUNDRA M C, et al. Influence of inorganic fertilizers and organic amendments on soil organic matter and soil microbial properties under tropical conditions[J]. Biology and Fertility of Soils, 1999, 29(2):196-200. doi: 10.1007/s003740050544 URL
[13]	张秀捷, 孔清华, 李光永, 等. 滴灌带间距和滴头间距对黄瓜产量的影响及经济效益分析[J]. 节水灌溉, 2010(9):81-83.
[14]	王维娟, 牛文全, 孙艳琦, 等. 滴头间距对双点源交汇入渗影响的模拟研究[J]. 西北农林科技大学学报(自然科学版), 2010, 38(4):219-225,234.
[15]	袁昌富, 李明思, 于英雷, 等. 滴头间距对线源滴灌土壤湿润均匀度的影响[J]. 石河子大学学报(自然科学版), 2010, 28(4):492-496.
[16]	李宝深. 滴灌蕉园养分综合管理技术研究与应用—以广西金穗为例[J]. 中国农业文摘-农业工程, 2016, 28(5):26.
[17]	XINGFA H, ZHOUBI Z, ZEJUN H. Suitable Technological Parameters of Mulched Drip Irrigation of Corn in Northwest China Irrigation Frequency and Drip Line Spacing[J]. Agricultural Engineering, 2019.
[18]	张文龙, 申磊, 王秀媛, 等. 焉耆盆地孜然与玉米间作种植对作物生产力及种间互作的影响[J]. 石河子大学学报(自然科学版), 2022:1-8.
[19]	云雷, 毕华兴, 马雯静, 等. 晋西黄土区果农间作土壤养分空间分布[J]. 农业工程学报, 2010(26):292-299.
[20]	许华森, 云雷, 毕华兴, 等. 核桃-大豆间作系统细根分布及地下竞争[J]. 生态学杂志, 2012, 31(7):1612-1616.
[21]	侯云鹏, 孔丽丽, 尹彩侠, 等. 覆膜滴灌下氮肥与种植密度互作对东北春玉米产量、群体养分吸收与转运的调控效应[J]. 植物营养与肥料学报, 2021, 27(1):54-65.
[22]	赵妍, 王凤新, 周奇, 等. 滴灌带间距和灌水定额对春小麦产量和水分利用效率的影响[J]. 中国农学通报, 2016, 32(14):194-199. doi: 10.11924/j.issn.1000-6850.casb15120040
[23]	胡敏, 苗庆丰, 史海滨, 等. 不同地膜覆盖对春玉米生长发育及水分利用效率的影响[J]. 干旱区资源与环境, 2017, 31(2):173-177.
[24]	许华森, 毕华兴, 高路博, 等. 晋西黄土区果农间作系统根系生态位特征[J]. 中国农学通报, 2013, 29(24):69-73.
[25]	MURLEY C B, SHARMA S, WARREN J G, et al. Yield response of corn and grain sorghum to row offsets on subsurface drip laterals[J]. Agricultural water management, 2018, 208:357-362. doi: 10.1016/j.agwat.2018.06.038 URL
[26]	XU Z Z, YU Z W, WANG D, et al. Nitrogen accumulation and translocation for winter wheat under different irrigation regimes[J]. Journal of agronomy and crop science, 2005, 191(6):439-449. doi: 10.1111/jac.2005.191.issue-6 URL
[27]	FAN Y, WANG Z, LIAO D, et al. Uptake and utilization of nitrogen, phosphorus and potassium as related to yield advantage in maize-soybean intercropping under different row configurations[J]. Scientific reports, London: Nature publishing group, 2020, 10(1):9504.
[28]	王月福, 于振文, 李尚霞, 等. 土壤肥力和施氮量对小麦氮素吸收运转及籽粒产量和蛋白质含量的影响[J]. 应用生态学报, 2003(11):1868-1872.
[29]	REN Y, ZHANG L, YAN M, et al. Effect of sowing proportion on above- and below-ground competition in maize-soybean intercrops[J]. Scientific reports, Berlin: Nature portfolio, 2021, 11(1):15760.
[30]	王旭洋, 范兴科. 水肥一体化滴灌条件下氮素在土壤中的时空分布特征[J]. 节水灌溉, 2016(6):55-58.

处理编号	灌水定额/(m³/hm²)
处理编号	分枝期(5.27—6.16, 20 d)	开花结荚期(6.17—7.21, 35 d)	鼓粒期(7.22—8.20, 30 d)
M1L1	711	822	86.2
M1L2	711	777	92
M1L3	711	555	110
CK1	0	0	0
M0L1	711	893	94.2
M0L2	711	800	80.6
M0L3	711	933	99.1
CK0	0	0	0

处理编号	灌水定额/(m³/hm²)
处理编号	分枝期(5.27—6.16, 20 d)	开花结荚期(6.17—7.21, 35 d)	鼓粒期(7.22—8.20, 30 d)
M1L1	711	822	86.2
M1L2	711	777	92
M1L3	711	555	110
CK1	0	0	0
M0L1	711	893	94.2
M0L2	711	800	80.6
M0L3	711	933	99.1
CK0	0	0	0

处理	铵态氮			硝态氮			速效钾			速效磷
处理	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm
M1L1	0.92^*	0.76ns	0.50ns	-0.56ns	3.99ns	11.38^*	6.36^*	5.57ns	4.68^*	2.33ns	2.60ns	0.60^*
M1L2	0.96^*	0.80ns	-0.22 ns	9.15^*	5.89^**	5.79^**	9.22^**	6.33^**	4.88^*	3.22^**	1.51^*	2.03^*
M1L3	1.04^*	1.10^*	0.34ns	6.94^*	4.94^*	4.30^*	4.14^*	4.10^*	3.90ns	1.24ns	1.10^*	0.68ns
CK1	1.01^**	0.93^**	0.46^*	7.81^**	4.50^**	3.76^*	4.50^*	3.90^**	3.10^*	0.80^**	0.48^**	0.41^*
M0L1	0.97^*	0.88^*	0.24ns	2.90ns	4.37ns	5.29ns	9.9ns	4.82ns	5.10ns	2.56^*	1.72ns	1.31^*
M0L2	0.97^**	0.64^**	0.39ns	4.82^*	8.52^*	2.77^*	6.16^**	3.70^**	3.30^**	1.79^**	1.21^**	1.13^*
M0L3	0.86ns	0.63ns	0.48ns	3.40ns	2.99ns	2.97^*	4.60^*	3.80^*	2.80ns	1.26^*	0.46ns	0.47^*
CK0	0.86^**	0.66^*	0.26^*	5.68^**	4.01^**	2.78^*	3.84^**	4.50^**	5.70^**	0.55^**	0.33^**	0.29^*

处理	铵态氮			硝态氮			速效钾			速效磷
处理	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm
M1L1	0.92^*	0.76ns	0.50ns	-0.56ns	3.99ns	11.38^*	6.36^*	5.57ns	4.68^*	2.33ns	2.60ns	0.60^*
M1L2	0.96^*	0.80ns	-0.22 ns	9.15^*	5.89^**	5.79^**	9.22^**	6.33^**	4.88^*	3.22^**	1.51^*	2.03^*
M1L3	1.04^*	1.10^*	0.34ns	6.94^*	4.94^*	4.30^*	4.14^*	4.10^*	3.90ns	1.24ns	1.10^*	0.68ns
CK1	1.01^**	0.93^**	0.46^*	7.81^**	4.50^**	3.76^*	4.50^*	3.90^**	3.10^*	0.80^**	0.48^**	0.41^*
M0L1	0.97^*	0.88^*	0.24ns	2.90ns	4.37ns	5.29ns	9.9ns	4.82ns	5.10ns	2.56^*	1.72ns	1.31^*
M0L2	0.97^**	0.64^**	0.39ns	4.82^*	8.52^*	2.77^*	6.16^**	3.70^**	3.30^**	1.79^**	1.21^**	1.13^*
M0L3	0.86ns	0.63ns	0.48ns	3.40ns	2.99ns	2.97^*	4.60^*	3.80^*	2.80ns	1.26^*	0.46ns	0.47^*
CK0	0.86^**	0.66^*	0.26^*	5.68^**	4.01^**	2.78^*	3.84^**	4.50^**	5.70^**	0.55^**	0.33^**	0.29^*

处理	有机质			全氮			全磷
处理	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm	0~20 cm	20~40 cm	40~60 cm
M1L1	1.13^*	0.48ns	0.23ns	0.18^*	-0.01ns	-0.01ns	0.13ns	0.07ns	0.02^*
M1L2	1.43^**	0.27^**	0.37ns	0.11^*	0.08^**	0.06^*	0.29ns	0.06^*	0.07^*
M1L3	0.83ns	0.45^*	0.19^*	0.06ns	0.05ns	0.09ns	0.09ns	0.02ns	0.04ns
CK1	0.60^*	0.40^*	0.33^**	0.03ns	0.01^*	0.04^**	0.17^**	0.02^**	0.06^**
M0L1	1.89ns	0.51^*	0.41^*	0.07^*	0.03ns	0.03^*	0.24ns	0.04ns	0.03ns
M0L2	1.25^*	0.37^**	0.41^**	0.05ns	0.02^**	0.03^**	0.06^**	0.03^**	0.03ns
M0L3	0.89ns	0.46ns	0.17ns	0.04ns	0.02ns	0.03ns	0.05^*	0.02^**	0.04^*
CK0	0.49^**	0.30^*	0.27^*	0.03^**	0.02^*	0.05^*	0.07^**	0.03ns	0.06^*
