Determination of Glyphosate, Ammonium Phosphate and Ammonia in Tea by UHPLC-MS

doi:10.11924/j.issn.1000-6850.casb20190900621

Abstract

Abstract:

A method is developed for the determination of glufosinate-ammonium (GLUF), glyphosate (PMG) and aminomethylphosphonic acid (AMPA) in tea using ultra performance liquid chromatography-tandem mass spectrometry (UPLC-MS/MS). The sample is extracted with ultrapure water and dichloromethane under ultrasonication, followed by a simple cleanup with a C18 solid phase extraction (SPE) cartridge, and then GLUF, PMG and AMPA are derivatized using 9-fluorenylmethoxycarbonyl (FMOC-Cl) in borate buffer. The derivatives of GLUF, PMG and AMPA are separated on a Waters HSS T3 column in a gradient elution mode, and finally detected with positive electrospray ionization-mass spectrometry (ESI-MS/MS) in multiple reaction monitoring (MRM) mode. The quantification analysis is performed by external standard method. The method shows a good linearity (R²>0.999) in the range of 0-100 ng/mL. The limit of detection (LODs) of GLUF, PMG and AMPA is 0.7 g/kg. At the spiked level of 2.0, 4.0和10.0 μg/kg, the recovery of GLUF, PMG and AMPA is 86.3%-100.2%,85.7%-101.5%, and 88.1%-98.4%, respectively, and the relative standard deviation (RSDs) (n=6) of GLUF, PMG and AMPA is 1.1%-5.0% respectively. This method is simple, rapid and characterized with acceptable sensitivity and accuracy to meet the requirements for the analysis of GLUF, PMG and AMPA simultaneously in tea.

Key words: UHPLC-MS, glyphosate, glufosinate-ammonium, aminomethylphosphonic acid, tea

CLC Number:

O658

Liu Wenjing, Lin Jing, Fu Jianwei, Wu Jianhong. Determination of Glyphosate, Ammonium Phosphate and Ammonia in Tea by UHPLC-MS[J]. Chinese Agricultural Science Bulletin, 2020, 36(25): 129-136.

Figures/Tables 9

References 25

[1]	徐娟, 陈捷, 叶弘毅, 等. QuEChERS提取与高效液相色谱-电喷雾电离串联质谱联用法检测茶叶中的19种农药残留[J]. 分析测试学报, 2011,30(9):990-995.
[2]	李致宝, 韦少平, 翁德洪, 等. 空气(氧气)氧化法制草甘膦的研究进展[J]. 化工技术与开发, 2009,38(10):31-33.
[3]	Yoshioka N, Asano M, Kuse A, et al. Rapid determination of glyphosate, glufosinate, bialaphos, and their major metabolites in serum by liquid chromatography-tandem mass spectrometry using hydro-philic interaction chromatography[J]. J Chromatogr A, 2011,1218(23):3675-3680. URL pmid: 21530973
[4]	Williams G M, Kroes R, Munro I C. Safety evaluation and risk assessment of the herbicide roundup and Its active ingredient, Glyphosate, for Humans[J]. Regul Toxicol Pharmacol, 2000,31:117-165. doi: 10.1006/rtph.1999.1371 URL pmid: 10854122
[5]	王非. 农达41%草甘膦对人L-02肝细胞损伤的研究[D]. 长沙:中南大学, 2008.
[6]	窦建瑞, 钱晓勤, 毛一扬, 等. 草甘膦对人体的毒性研究进展[J]. 江苏预防医学, 2013,24(6):43-45.
[7]	谢旭蓉. 土壤中残留草铵膦对油菜移栽幼苗膜脂氧化及其氮同化代谢的影响[D]. 重庆:西南大学, 2017.
[8]	曹伦, 周岳明, 王明锋. Strecker法合成草铵膦的工艺及注意事项[J]. 科教导刊, 2015(5):37-38.
[9]	吴晓刚, 陈孝权, 肖海军, 等. 柱前衍生-超高效液相色谱-串联质谱法同时检测茶叶中草甘膦和草铵膦的残留量[J]. 色谱, 2015,33(10):1090-1096. doi: 10.3724/SP.J.1123.2015.04045 URL
[10]	叶美君, 朱明, 杜颖颖, 等. 茶园主要除草剂草甘膦和草铵膦概述[J]. 中国茶叶加工, 2017(5):32-37.
[11]	裴亚峰, 樊振江, 曹金博, 等. 免疫分析技术在草甘膦残留检测中的应用[J]. 中国免疫学杂志, 2018,34(2):291-295.
[12]	杨华梅, 杭莉. 柱前衍生高效液相色谱法测定饮用水中草甘膦、草铵膦和氨甲基膦酸[J]. 卫生研究, 2015,44(4):671-674.
[13]	张超, 李腾飞, 赵风年, 等. 分子印迹电化学传感器的制备及其快速检测饮水中草甘膦残留的应用研究[J]. 分析测试学报, 2016,35(12):1542-1547.
[14]	李小娟, 孟品佳, 王燕燕, 等. 毛细管电泳-间接紫外法测定饮用水中草甘膦、草铵膦及其代谢产物[J].理化检验:化学分册, 2015(3):307-311.15.
[15]	罗彤, 付文雯, 郭卢云, 等. 离子色谱法测定不同谷物中草甘膦残留[J]. 食品安全质量检测学报, 2018,9(1):161-166.
[16]	马非非, 齐宝坤, 谭家镒. 水库水中草甘膦和草铵膦的国产树脂萃取-硅烷衍生化-气质联用分析法[J]. 中国刑警学院学报, 2010(1):61-64.
[17]	成婧, 王美玲, 龚强, 等. 液相色谱-串联质谱法检测植物源食品中草甘膦及其代谢物的残留量[J]. 食品安全质量检测学报, 2016,7(1):138-144.
[18]	刘正才, 蔡春平, 林永辉, 等. 分散固相萃取/液相色谱-串联质谱法测定茶叶中草甘膦及其代谢物氨甲基膦酸的残留量[J]. 分析测试学报, 2015,34(3):335-340.
[19]	中华人民共和国国家质量监督检验检疫局. SN/T 1923—2007 进出口食品中草甘膦残留量的检测方法液相色谱质谱/质谱法. 北京: 中国标准出版社, 2007.
[20]	Ding J, Jin G, Jin G, et al. Determination of underivatized glyphosate residues in plant-derived food with low matrix effect by solid phase extraction-liquid chromatography-tandem mass spectrometry[J]. Food Analytical Methods, 2016(10):2856-2863.
[21]	Todorovic G R, Mentler A, Popp M, et al. Determination of glyphosate and AMPA in three representative agricultural Austrian soils with a HPLC-MS/MS method[J]. Soil and Sediment Contamination: An International Journal, 2013,22(3):332-350. doi: 10.1080/15320383.2013.726296 URL
[22]	Guo H, Riter L S, Wujcik C E, et al. Direct and sensitive determination of glyphosate and aminomethylphosphonic acid in environmental water samples by high performance liquid chromatography coupled to electrospray tandem mass spectrometry[J]. Journal of Chromatography A, 2016(14):93-100.
	冯月超, 马立利, 贾丽, 等. 多壁碳纳米管分散固相萃取-液质联用技术测定茶叶中草甘膦、草铵膦、氨甲基膦酸残留量[J]. 食品安全质量检测学报, 2014(4):1147-1154.
[24]	刘正才, 蔡春平, 林永辉, 等. 分散固相萃取/液相色谱-串联质谱法测定茶叶中草甘膦及其代谢物氨甲基膦酸的残留量[J]. 分析测试学报, 2015,34(3):335-340.
[25]	钟茂生, 梁剑, 朱品玲, 等. HPLC-MS-MS法测定茶叶中的草甘膦和氨甲基膦酸[J]. 广州化工, 2014,42(22):128-130.

化合物	保留时间/min	母离子(m/z)	子离子(m/z)	去簇电压/V	碰撞能量/eV
草甘膦	3.74	392.1	170^*,214	27,27	28,14
草铵膦	3.97	404	136^*,179	30,27	29,16
氨甲基膦酸	3.83	334	112^*,156	22,30	24,19
草甘膦内标	3.74	393.5	179.32^*,214.86	25,25	9,10

化合物	保留时间/min	母离子(m/z)	子离子(m/z)	去簇电压/V	碰撞能量/eV
草甘膦	3.74	392.1	170^*,214	27,27	28,14
草铵膦	3.97	404	136^*,179	30,27	29,16
氨甲基膦酸	3.83	334	112^*,156	22,30	24,19
草甘膦内标	3.74	393.5	179.32^*,214.86	25,25	9,10

分析物	回归方程	线性范围/(ng/mL)	相关系数(r²)	检出限/(μg/kg)	定量限/(μg/kg)
草甘膦	y=420.7x+39.7	1~100	0.9993	0.7	2.0
草铵膦	y=909.4x-67.6	1~100	0.9995	0.7	2.0
氨甲基膦酸	y=1595.7x-52.8	1~100	0.9991	0.7	2.0

分析物	回归方程	线性范围/(ng/mL)	相关系数(r²)	检出限/(μg/kg)	定量限/(μg/kg)
草甘膦	y=420.7x+39.7	1~100	0.9993	0.7	2.0
草铵膦	y=909.4x-67.6	1~100	0.9995	0.7	2.0
氨甲基膦酸	y=1595.7x-52.8	1~100	0.9991	0.7	2.0
