Water and Nitrogen Coupling Effects and Model Under Tomato Drip Irrigation

doi:10.11924/j.issn.1000-6850.casb2021-0190

Abstract

Abstract:

To explore the irrigation and fertilization system and the optimal coupling mode of water and nitrogen (N) for high-yield, high-quality and high-efficiency of tomato production under drip irrigation, a field experiment was conducted to investigate the effects of different water and N coupling modes on tomato yield, quality, and water and N use under drip irrigation. The results showed that compared with F₀W₀ (100% N fertilizer applied to soil as basal fertilizer and rainfall + supplementary drip irrigation), F₂W₂ (100% N fertilizer via alternate drip irrigation and 80% conventional irrigation amount), F₃W₂ (40% N fertilizer applied to soil as basal fertilizer, 60% N fertilizer via alternate drip irrigation as topdressing and 80% conventional irrigation amount), F₄W₂ (100% N fertilizer via fixed drip irrigation and 80% conventional irrigation amount) and F₅W₂ (40% N fertilizer applied to soil as basal fertilizer, 60% N fertilizer via fixed drip irrigation as topdressing and 80% conventional irrigation amount) increased tomato yield, water use efficiency and partial productivity of N fertilizer. F₂W₂enhanced vitamin C, soluble sugar and sugar/acid ratio of tomato by 42.5%, 25.5% and 131.9%, respectively. F₂W₂ had the optimal comprehensive quality of tomato evaluated by principal component analysis, and the optimal comprehensive benefit of tomato yield, quality, and water and N use evaluated by TOPSIS. Therefore, 100% N fertilizer via alternate drip irrigation and 80% conventional irrigation amount (F₂W₂) is the optimal coupling mode of water and N for tomato under drip irrigation.

Key words: water and nitrogen coupling, alternate drip irrigation, yield, quality, water and nitrogen use, tomato

CLC Number:

S147

LUO Hui, LI Fusheng. Water and Nitrogen Coupling Effects and Model Under Tomato Drip Irrigation[J]. Chinese Agricultural Science Bulletin, 2022, 38(3): 30-36.

Figures/Tables 8

References 26

[1]	康绍忠, 张建华, 梁宗锁, 等. 控制性交替灌溉一种新的农田节水调控思路[J]. 干旱地区农业研究, 1997, 15(1):4-9.
[2]	唐汉, 王金武, 徐常塑, 等. 化肥减施增效关键技术研究进展分析[J]. 农业机械学报, 2019, 50(4):1-19.
[3]	FU F B, LI F S, KANG S Z. Alternate partial root-zone drip irrigation improves water-and nitrogen-use efficiencies of sweet-waxy maize with nitrogen fertigation[J]. Scientific reports, 2017, 7:17256. doi: 10.1038/s41598-017-17560-2 URL
[4]	LUO H, LI F S. Tomato yield, quality and water use efficiency under different drip fertigation strategies[J]. Scientia horticulturae, 2018, 23(5):181-188. doi: 10.1016/0304-4238(84)90022-0 URL
[5]	LIU R, YANG Y, WANG Y S, et al. Alternate partial root-zone drip irrigation with nitrogen fertigation promoted tomato growth, water and fertilizer-nitrogen use efficiency[J]. Agricultural water management, 2020, 233:1-8.
[6]	胡晓辉, 高子星, 马永博, 等. 基于产量品质及水肥利用率的袋培辣椒水肥耦合方案[J]. 农业工程学报, 2020, 36(17):81-89.
[7]	邢英英, 张富仓, 张燕, 等. 滴灌施肥水肥耦合对温室番茄产量、品质和水氮利用的影响[J]. 中国农业科学, 2015, 48(4):713-726.
[8]	刘中良, 谷端银, 张艳艳, 等. 水氮因子耦合对日光温室基质栽培番茄品质、产量及水氮利用率的影响[J]. 中国农业科技导报, 2019, 21(2):111-119.
[9]	王超, TANKARI Moussa, 龚道枝, 等. 优质樱桃番茄高效水氮耦合管理[J]. 植物营养与肥料学报, 2020, 26(1):120-130.
[10]	李文玲, 孙西欢, 张建华, 等. 水氮耦合对膜下滴灌设施番茄水氮生产函数影响研究[J]. 灌溉排水学报, 2021, 40(1):47-54.
[11]	王贺辉, 赵恒, 高强, 等. 温室番茄滴灌灌水指标试验研究[J]. 节水灌溉, 2005, 5:22-25.
[12]	鲁如坤. 土壤农业化学分析方法[M]. 北京: 中国农业科技出版社, 2000.
[13]	李合生, 孙群, 赵世杰, 等. 植物生理生化实验原理和技术[M]. 北京: 高等教育出版社, 2000.
[14]	韩泽群, 姜波. 加工番茄品种多性状综合评价方法研究[J]. 中国农业科学, 2014, 47(2):357-365.
[15]	徐心诚. 主成分分析法对番茄品种耐弱光性的综合评价[J]. 中国农学通报, 2012, 28(4):135-140.
[16]	DENG H, YEH C H, WILLIS R J. Inter-company comparison using modified TOPSIS with objective weights[J]. Computers and operations research, 2000, 27(10):963-973. doi: 10.1016/S0305-0548(99)00069-6 URL
[17]	WANG F, DU T S, QIU R J. Deficit irrigation scheduling of greenhouse tomato based on quality principle component analysis[J]. Transactions of the CSAE, 2011, 27(1):75-80.
[18]	KUO T. A modified TOPSIS with a different ranking index[J]. European journal of operational rese, 2017, 260:152-160.
[19]	ZHAO D, WANG Z H, ZHANG J Z, et al. Improving yield and quality of processing tomato (Lycopersicon esculentum Miller) using alternate partial root-zone drip irrigation in arid Northwest China[J]. Water, 2019, 11(7):1503-1503. doi: 10.3390/w11071503 URL
[20]	刘学娜, 刘彬彬, 崔青青, 等. 交替滴灌施氮对日光温室黄瓜生长、光合特性、产量及水氮利用效率的影响[J]. 植物生理学报, 2016, 52(6):905-916.
[21]	李洪任, 卢江海, 邢文刚, 等. 根系分区交替滴灌周期对番茄产量品质及水分利用效率的影响[J]. 节水灌溉, 2015, 5:34-41.
[22]	WANG J W, LI Y, NIU W Q. Deficit Alternate Drip Irrigation Increased Root-Soil-Plant Interaction, Tomato Yield, and Quality[J]. International journal of environmental research and public health, 2020, 17(3):781-789. doi: 10.3390/ijerph17030781 URL
[23]	商美新, 房增国, 梁斌, 等. 不同水氮处理对膜下滴灌马铃薯产量、品质及土壤硝态氮运移的影响[J]. 华北农学报, 2019, 34(6):118-125.
[24]	赵娣, 王振华, 李文昊, 等. 分根区交替灌溉对膜下滴灌加工番茄根系特征及产量的影响[J]. 核农学报, 2018, 32(10):2069-2079.
[25]	WANG Z, LIU Z, ZHANG Z, et al. Subsurface drip irrigation scheduling for cucumber (Cucumis sativus L.) grown in solar greenhouse based on 20cm standard pan evaporation in Northeast China[J]. Scientia horticulturae, 2009, 123(1):51-57. doi: 10.1016/j.scienta.2009.07.020 URL
[26]	ZHANG Q, WU S, CHEN C, et al. Regulation of nitrogen forms on growth of eggplant under partial root-zone irrigation[J]. Agricultural Water management, 2014, 142:56-65. doi: 10.1016/j.agwat.2014.04.015 URL

处理	N基肥比例	各生育期追施N比例/%								各生育期灌水量/mm
	N基肥比例	苗期		开花期		果实膨大期		果实成熟期		苗期		开花期		果实膨大期		果实成熟期
	10-25	11-5	11-12	11-20	11-27	12-4	12-12	12-20	12-30	11-5	11-12	11-20	11-27	12-4	12-12	12-20	12-30
F₀W₀	100	0	0	0	0	0	0	0	0	0	0	43.2	0	47.5	0	45.6	0
F₁W₁	100	0	0	0	0	0	0	0	0	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₂W₁	0	5	5	15	15	15	15	15	15	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₂W₂	0	5	5	15	15	15	15	15	15	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₃W₂	40	3	3	9	9	9	9	9	9	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₄W₁	0	5	5	15	15	15	15	15	15	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₄W₂	0	5	5	15	15	15	15	15	15	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₅W₂	40	3	3	9	9	9	9	9	9	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3

处理	N基肥比例	各生育期追施N比例/%								各生育期灌水量/mm
	N基肥比例	苗期		开花期		果实膨大期		果实成熟期		苗期		开花期		果实膨大期		果实成熟期
	10-25	11-5	11-12	11-20	11-27	12-4	12-12	12-20	12-30	11-5	11-12	11-20	11-27	12-4	12-12	12-20	12-30
F₀W₀	100	0	0	0	0	0	0	0	0	0	0	43.2	0	47.5	0	45.6	0
F₁W₁	100	0	0	0	0	0	0	0	0	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₂W₁	0	5	5	15	15	15	15	15	15	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₂W₂	0	5	5	15	15	15	15	15	15	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₃W₂	40	3	3	9	9	9	9	9	9	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₄W₁	0	5	5	15	15	15	15	15	15	57.3	60.1	63.2	59.4	64.2	58.5	64.7	61.6
F₄W₂	0	5	5	15	15	15	15	15	15	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3
F₅W₂	40	3	3	9	9	9	9	9	9	45.8	48.1	50.6	47.5	51.4	46.8	51.8	49.3

处理	果实含水率/%	果型指数	果实硬度	番茄红素/ (mg/100 g)	维生素C/ (mg/100 g)	可溶性固形物/%	水溶性糖/%	有机酸/%	糖酸比
F₀W₀	91.0±0.4a	0.87±0.03a	5.4±0.4b	9.5±1.3a	18.1±2e	7.3±0.3a	5.1±0.6c	0.45±0.04a	11.6±1.4d
F₁W₁	91.6±0.9a	0.87±0.02a	6.2±0.3ab	9.8±0.3a	19.8±0.6de	8.0±0.1a	5.2±0.1c	0.26±0.02b	20.0±1.3bc
F₂W₁	92.2±0.4a	0.88±0.02a	6.0±0.4b	9.8±0.9a	22.2±1.2bcd	7.6±0.4a	6.4±0.4a	0.30±0.03b	21.6±2.6ab
F₂W₂	92.3±0.6a	0.88±0.03a	5.7±0.4b	9.7±0.9a	25.8±2.1a	7.9±0.4a	6.3±0.5ab	0.24±0.03b	26.9±5.3a
F₃W₂	91.3±0.9a	0.88±0.01a	6.3±0.8ab	10.1±2.5a	24.3±1.6ab	8.0±0.3a	5.9±0.2abc	0.40±0.07a	15.0±2.5cd
F₄W₁	92.1±1.2a	0.89±0.03a	6.4±0.7ab	9.6±1.6a	21.1±2cd	7.3±0.3a	5.5±0.5bc	0.30±0.03b	18.4±3.1bc
F₄W₂	91.3±0.8a	0.88±0.03a	7.3±0.6a	8.7±1.0a	23.8±1.5abc	7.4±0.7a	5.9±0.7abc	0.29±0.05b	20.7±4.3bc
F₅W₂	92.0±0.9a	0.86±0.04a	6.5±0.7ab	10.5±2.2a	21.1±1.0cd	7.2±0.5a	5.7±0.2abc	0.31±0.04b	18.1±2.8bc
显著性检验（P值）	0.352	0.896	0.039	0.913	<0.001	0.110	0.018	<0.001	0.001

处理	果实含水率/%	果型指数	果实硬度	番茄红素/ (mg/100 g)	维生素C/ (mg/100 g)	可溶性固形物/%	水溶性糖/%	有机酸/%	糖酸比
F₀W₀	91.0±0.4a	0.87±0.03a	5.4±0.4b	9.5±1.3a	18.1±2e	7.3±0.3a	5.1±0.6c	0.45±0.04a	11.6±1.4d
F₁W₁	91.6±0.9a	0.87±0.02a	6.2±0.3ab	9.8±0.3a	19.8±0.6de	8.0±0.1a	5.2±0.1c	0.26±0.02b	20.0±1.3bc
F₂W₁	92.2±0.4a	0.88±0.02a	6.0±0.4b	9.8±0.9a	22.2±1.2bcd	7.6±0.4a	6.4±0.4a	0.30±0.03b	21.6±2.6ab
F₂W₂	92.3±0.6a	0.88±0.03a	5.7±0.4b	9.7±0.9a	25.8±2.1a	7.9±0.4a	6.3±0.5ab	0.24±0.03b	26.9±5.3a
F₃W₂	91.3±0.9a	0.88±0.01a	6.3±0.8ab	10.1±2.5a	24.3±1.6ab	8.0±0.3a	5.9±0.2abc	0.40±0.07a	15.0±2.5cd
F₄W₁	92.1±1.2a	0.89±0.03a	6.4±0.7ab	9.6±1.6a	21.1±2cd	7.3±0.3a	5.5±0.5bc	0.30±0.03b	18.4±3.1bc
F₄W₂	91.3±0.8a	0.88±0.03a	7.3±0.6a	8.7±1.0a	23.8±1.5abc	7.4±0.7a	5.9±0.7abc	0.29±0.05b	20.7±4.3bc
F₅W₂	92.0±0.9a	0.86±0.04a	6.5±0.7ab	10.5±2.2a	21.1±1.0cd	7.2±0.5a	5.7±0.2abc	0.31±0.04b	18.1±2.8bc
显著性检验（P值）	0.352	0.896	0.039	0.913	<0.001	0.110	0.018	<0.001	0.001

处理	产量	耗水量	水分利用效率	氮肥偏生产力	果实含水率	果型指数	果实硬度	番茄红素	维生素C	可溶性固形物	水溶性糖	有机酸	糖酸比	d⁺	d^-	CI	排序
F₀W₀	0.27951	0.30697	0.31296	0.27947	0.35075	0.35101	0.30558	0.34539	0.28889	0.33987	0.31267	0.48870	0.21024	0.03264	0.00835	0.20366	8
F₁W₁	0.33102	0.40362	0.28187	0.33109	0.35307	0.35101	0.35085	0.35630	0.31602	0.37246	0.31880	0.28236	0.36248	0.01907	0.02081	0.52184	5
F₂W₁	0.34780	0.40362	0.29605	0.34786	0.35538	0.35505	0.33953	0.35630	0.35433	0.35383	0.39236	0.32580	0.39147	0.01627	0.02150	0.56928	4
F₂W₂	0.36007	0.32290	0.38337	0.36005	0.35577	0.35505	0.32255	0.35266	0.41179	0.36780	0.38623	0.26064	0.48753	0.01255	0.02958	0.70222	1
F₃W₂	0.39637	0.32290	0.42193	0.39633	0.35191	0.35505	0.35651	0.36720	0.38785	0.37246	0.36171	0.43440	0.27186	0.02232	0.01921	0.46260	7
F₄W₁	0.34428	0.40362	0.29306	0.34428	0.35499	0.35908	0.36217	0.34903	0.33677	0.33987	0.33719	0.32580	0.33348	0.01786	0.01944	0.52120	6
F₄W₂	0.36818	0.32290	0.39183	0.36822	0.35191	0.35505	0.41310	0.31631	0.37987	0.34452	0.36171	0.31494	0.37516	0.01263	0.02429	0.65788	2
F₅W₂	0.38793	0.32290	0.41297	0.38787	0.35461	0.34698	0.36783	0.38175	0.33677	0.33521	0.34945	0.33666	0.32804	0.01578	0.02200	0.58227	3
A⁺	0.02832	0.02198	0.02990	0.02831	0.02563	0.02587	0.02962	0.02746	0.02938	0.02679	0.02811	0.01847	0.01470
A^-	0.01997	0.02889	0.01998	0.01996	0.02527	0.02500	0.02191	0.02275	0.02061	0.02411	0.02240	0.03463	0.03408
R	0.671	-0.079	0.329	0.671	0.656	0.220	0.520	0.162	0.741^*	0.211	0.689	-0.878^**	0.892^**
